The R4 is designed to provide optimum accuracy and reliability
for demanding shipboard applications.
The system offers IMO compliant precision and a built in
12 channel GPS receiver. The R4 dual-channel DGPS beacon
receiver is designed to meet all requirements for commercial
marine applications. The System performes continuous RAIM
(Receiver Autonomous Integrity Monitoring) calculations. This
allows to set the required navigation accuracy for any stage of
the journey.
|
|
- FEATURES
GPS sensor GPS 100 or DGPS sensor DGPS 200 can be connected.
Large LCD display to provide may graphic modes (CDI mode, Plot mode, etc).
Up to 20 routes and 499 waypoints are easily stored.
- EASY INSTALLATLON & OPERATION
Mount the J-NAV 500 display unit anywhere you want because it's totally splashproof.
Connect the optional GPS 100 GPS Sensor or DGPS 200 DGPS Sensor and it continuously tracks 8 satellites to give you an instant and accurate GPS position.
Select a NAV, CDI, position or plotting screen 1/8 to 100nm scale and easily customize the display to show the information you need.
With DGPS200 DGPS Sensor, you fixes will always be accurate with 15 feet (5meters).
20 routes and 499 waypoints can be stored in the J-NAV500. Scroll through them numerically of alphabetically.
|
|
- Internal SBAS receiver
The GPS124 includes a SBAS (WAAS/EGNOS/MSAS) receiver.
By using SBAS you can achieve precise position.
- RAIM function
The accuracy of position fixes is self-tested by the GPS124. (RAIM function)
This function assures higher reliability to the position fix than conventional method.
- 12-Channel Parallel for Receiving 12 Satellites Simultaneously
The GPS 124 is designed to simultaneously receive signals from 12 orbiting satellites, ensuring the most accurate positioning.
- IEC61162-1, NMEA0183 Output
Since the output data is changeable between IEC61162-1 (NMEA0183 version 2.3), NMEA version 1.5 and 2.1, you can connect the GPS124 to various Marine Electronics Equipment such as Marine Radars, Fishfinders, Plotters, or others.
|
|
|
|
|
|
|
Flexible Rugged High-Performance GNSS Receiver
Designed by our GNSS experts, the new ProFlexâ"¢ 500 is a powerful positioning solution that delivers state-of-the-art RTK in a rugged, highly integrated receiver design. Embedded BLADEâ"¢ technology ensures powerful RTK performance and a patented way to use multiple GNSS constellations for high-accuracy positioning and surveying solutions.
Rugged and Integrated Design
The ProFlex 500 offers a unique set of embedded communication features for maximum flexibility and resistance to bad weather. It contains completely integrated GSM, UHF and Bluetooth for wireless communications as well as Ethernet, RS-232/422 and USB connections. All output connections are optically isolated to prevent problems with installation in shipboard applications.
Made to withstand harsh environments, its environmental characteristics include: 100% condensing humidity proof, salt mist resistant, shock and vibration resistant as defined in military standard MIL STD 810 F. The receiver has an extremely rugged aluminum housing and is IP67 rated.
Flexible Solution
The ProFlex 500 innovative design makes it the ideal solution for onboard system integration - it can be easily mounted on a ship or on a vehicle for sea or land operations - and it is also a perfect backpack rover or base station solution for precise land surveying.
Adaptable to most any specific positioning usage, the ProFlex 500 is the answer for users looking for a single GNSS receiver for multiple applications. It is for example, a perfect solution for the hydrography services and dredging companies performing both onshore and offshore RTK surveys. ProFlex 500 enables optimal equipment use and simpler deployment among survey crews.
High-end Performance
ProFlex 500 offers GPS+GLONASS+20 years of field-proven Magellan technologies. It is made to withstand harsh environments, and gives you maximum flexibility on sea and land.
Fast initialization and centimeter accuracy at long-range
Unique BLADE technology for full benefit of any available GLONASS corrections
Unique built-in communication features
Rugged design for demanding work environments
Advanced multi-path mitigation and robust signal tracking for maximum data reliability
Interoperability with any vendor's reference station transmitting GPS+GLONASS L1/L2
|
|
- Internal WAAS receiver
(DGPS 212W)
The DGPS212W includes a WAAS receiver. By Using WAAS you can achieve precise position.
- Internal Differential Beacon Receiver
The DGPS 212 includes a Beacon Receiver and a GPS Receiver.
By using DGPS you can achieve true DGPS accuracy.
- 12-Channel Parallel for Receiving 12 Satellites Simultaneously
The DGPA 212 is designed to simultaneously receive from 12 orbiting satellites, ensuring the most accurate positioning.
- Quick Position Fixing
Typically 45 seconds for first position fixing without GPS almanac data.
- Conversion to NMEA183 Output
Since the NMEA0183 output data is changeable between version 1.5 and version 2.1 you can connect the DGPS 212 to various Marine Electronics Equipment such as Marine Radars, Fishfinders, Plotters, or others.
- PPS Signal Output
The DGPS 212 outputs a pulse per second which coincides with UTC second precisely. It can be used as a precise clock.
|
|
|
|
