Turnbuckle US type, Material with AISI 304 or AISI 316
Finished two types: Precision Cast and Forged
size: 1/4", 5/16", 3/8", 1/2", 5/8", 3/4", 1", 1-1/4"
Turnbuckle Jaw & Jaw, Turnbuckle Stub & Stub, turnbuckle Jaw and Eye,
turnbuckle Body only, Turnbuckle Eye & Eye, turnbuckle open Jaw and Jaw,
turnbuckle hook & eye, Turnbuckle eye and eye open body,
Turnbuckle hook and hook, turnbuckle hook and eye open body,
turnbuckle jaw and eye open body, turnbuckle toggle and swage,
turnbuckle toggle and toggle, turnbuckle toggle and swage,
turnbuckle jaw and swage closed body,
turnbuckle jaw and jaw open body
|
|
|
|
|
|
|
Turnbuckle (Closed Body) Jaw & Jaw 316 Stainless Steel, Formed & Machined
Stainless Steel AISI 316 (A4) Jaw & Jaw Rigging Screw Standard Type
Jaw & Jaw type usually named Fork & Fork Type.
This is a closed boldy turnbuckle. Use this turnbuckle for when the load is in-line and for architectural applications. This (Rigging screw)turnbuckle is not recommended for marine applications. Bodies are made of tubing, jaws are formed and then welded. Large custom sizes available
Size from 3/16"-5/8"
Note: Call us! Other sizes, styles and manufacturers are available on special order.
Others we can supply:
Rigging screws Jaw & JaAing Screws, Fork, Eye and screwed terminals
Rigging Screws, Fork, Eye and screwed terminals
Open body Turnbuckles Hook & Eye, Jaw & Jaw, Eye & Eye, Hook & Hook
Turnbuckle Frame type, DIN 1480 Standard; commerical Type
Turnbuckle DIN 1480, EYE and hook, Hook & hook, Eye and Eye
All by Precison Cast, made by Stainless Steel AISI 304 or AISI316.
Rigging Screw European Type
formed and Machined.
Swage Eye, Swage Stub, Swage Jaw, Swage Fork, Swage Toggle.
Stainless steel Architectural Assemblies
Marine stainless steel Fittings
Stainless steel Swageless Terminals
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67505 5 156 600
Turnbuckle HT67506 6 163 1,000
Turnbuckle HT67508 8 200 1,400
Turnbuckle HT67510 10 238 2,200
T.D.L. : Tested deformation load
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67205 5 126 750
Turnbuckle HT67206 6 135 1,400
Turnbuckle HT67208 8 159 2,200
Turnbuckle HT67210 10 198 3,450
T.D.L. : Tested deformation load
|
|
Made by Stainless STeel AIS316 INOX A4.
Closed body with fork and fork ( jaw and jaw)
European Standard, FORMED AND MACHINED.
SIZE from 5mm to 20MM.
PAcking in cartons and then on pallets.
Lead time: only 20 days after received confirmation.
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67105 5 120 750
Turnbuckle HT67106 6 144 1,400
Turnbuckle HT67108 8 160 2,200
Turnbuckle HT67110 10 200 3,450
T.D.L. : Tested deformation load
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67605 5 150 600
Turnbuckle HT67606 6 172 1,000
Turnbuckle HT67608 8 200 1,400
Turnbuckle HT67610 10 240 2,200
T.D.L. : Tested deformation load
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67305 5 131 500
Turnbuckle HT67306 6 142 900
Turnbuckle HT67308 8 169 1,650
Turnbuckle HT67310 10 207 2,500
T.D.L. : Tested deformation load
|
|
Oceanmaster Turnbuckles
Using precision casting for the external fork and double threaded welding on the bar, these turnbuckles provides high strength for minimum cost.
Anti-Jamming bronze inserts are used to guarantee the thread turns even under high tension operation. Rigid in design, the open frame also aids rinsing, helping to avoid unwanted sand / dirt / grease build up.
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67405 5 127 500
Turnbuckle HT67406 6 150 900
Turnbuckle HT67408 8 170 1,650
Turnbuckle HT67410 10 205 2,500
T.D.L. : Tested deformation load
|
|
Oceanmaster Turnbuckles
Using precision casting for the external fork and double threaded welding on the bar, these turnbuckles provides high strength for minimum cost.
Anti-Jamming bronze inserts are used to guarantee the thread turns even under high tension operation. Rigid in design, the open frame also aids rinsing, helping to avoid unwanted sand / dirt / grease build up.
|
|
Unless otherwise stated dimensions are in mm, weights in g and loads in kg.
Description Part Size L TDL
Turnbuckle HT67805 2.5xM5 160 670
Turnbuckle HT67806 3xM6 180 940
Turnbuckle HT67808 4xM6 171 1,400
Turnbuckle HT67810 4xM8 212 1,800
T.D.L. : Tested deformation load
|
|
Allows to optimize the rigging and sails performance
The handle offers great comfort during operations and greater onboard access
|
|
Oceanmaster Turnbuckles
Using precision casting for the external fork and double threaded welding on the bar, these turnbuckles provides high strength for minimum cost.
Anti-Jamming bronze inserts are used to guarantee the thread turns even under high tension operation. Rigid in design, the open frame also aids rinsing, helping to avoid unwanted sand / dirt / grease build up.
|
|
Stainless Steel Turnbuckles: Made by Stainless Aisi316 or AISI304, We can Supply the type of Toggle & Toggle and Toggle & Swage.
size with 3/16" 1/4" 5/16" 3/8" 1/2"
Please noted that Customer size and OEM are Acceptable.
Stainless Steel Turnbuckle Toggle and Toggle
Stainless Steel Turnbuckle Toggle and Swage
More detail please contact with TOOLEE GROUP INC. Qingdao lifting and rigging corp. info@rigginglifting.com
|
|
Selden rigging screws are made from high-grade, marine stainless steel.
The rigging screws have cold rolled threads and are polished for higher corrosion resistance. The threads are lubricated with Selden rigging screw oil prior to delivery. To keep your rigging screws in good condition, please clean and lubricate them regularly with our special rigging screw oil.
|
|
Sparcraft Rigging assembles and sells quality standing and running riggings. SP.R is based near RDM Sparcraft in La Rochelle, with whom a synergy allows to offer a mast/rigging package.
The selected parts are manufactured with the best alloys from European origin according to reliable and tested machining and forging methods. The numerous quality controls and a strict traceability placed SPR to the top of the rigging line.
|
|
|
Loos Cableware® Division provides the full line of MS21251 Turnbuckle Bodies (same as NAS649) in Brass, Steel, and Aluminum and use MS21256 Locking Clips to provide a positive lock with the mating part. Brass Turnbuckle Bodies are available with Nickel Plating for marine applications. Steel and Aluminum Turnbuckle Bodies are protected in accordance with MIL-DTL-8878. Loos Cableware® Division offers a full line of the MS21251 Turnbuckle Bodies and is a QPL manufacturer of these parts.
|
|
Stay Adjusters allow wire rigging systems to be altered by means of a clevis pin. All models constructed from stainless steel strip with different sizes and spacings.
The fine tune adjuster R4394 is a must for hotshot dinghy crews. Pivoting foot utilising three holes always gives a straight line between shroud and full anchorage point, plus a fine 2mm adjustment.
R4392 Shroud "SPINI" roller acts as guide for sheet when reaching. Fits all RWO shroud adjusters with 5mm, (3/16in.) holes.
Shroud Levers improve downwind performance by allowing the mast to lean forward and permitting the boom to be squared off. Another use of the lever is to instantly slacken the tension in standing rigging; both on boats and hang gliders. Two models are available, both having an easy to grip handle and adjustable throw. Both levers are strong enough for sailboats up to 5.9m. (18ft.) long and can be safely used in winds up to 20 knots.
|
|
Comprehensive range of traditional closed body rigging screws manufactured from high grade stainless steel with bright electropolished finish.
Tensioning can be achieved by using a tommy bar in the body central hole. Once tensioned, tighten lock nuts and feed ceasing wire round ends and through body hole.
For reliability all rigging products are regularly tested for fatigue and destruction to quoted figures.
NB End fittings can be varied to make other combinations i.e. Fork & Eye, Eye & Terminal etc. (50 min) within the style.
|
|
|
A highly sophisticated rigging screw, from the Blue Wave racing line. It features an adjustment nut in black chromed high quality alu bronze, engraved calibration scale for fast and accurate adjustment of the rig tension and an extra length threaded stemball.
|
|
|
The Blue Wave Chromed Bronze Body Rigging screw line features a number of details that makes it the best choice for exclusive and durable rigging.
|
|
|
The Blue Wave Chromed Bronze Body Rigging screw line features a number of details that makes it the best choice for exclusive and durable rigging.
|
|
|
The price favourable and durable Stainless Steel Rigging Screw line from Blue Wave has been a favourite among Riggers and yachtsmen for the last 50 years. It offers a wide variety of features. Laser engraved thread size, Blue Wave logo, and side marking of the left thread.
|
|
Harken® stay tensioners are reliable mechanical adjusters that are easy to install and simple to use. Tensioners are made of polished stainless steel and chromed bronze, and feature bronze worm gears and thread drives to prevent galling under load. Moving components are mounted on greased roller bearings for easy adjustment.
Tensioners come in four sizes for boats from 27 ft to 50 ft (8 m to 15 m) with backstays from 9/32 in to 1/2 in (7 mm to 12 mm). B1722 tensioners have fold-down adjustment handles. The other tensioners accept a standard winch handle and are available in custom lengths.
|
|
|
The Blue Wave Chromed Bronze Body features a number of details that makes it the best choice for exclusive and durable rigging. The sleek, open Bronze body prevents the threads from seizing up, they are delivered with laser engraved thread size, Blue Wave logo, and side marking of the left thread.
|
|
|
The price favourable and durable Stainless Steel Rigging Screw line from Blue Wave has been a favourite among Riggers and yachtsmen for the last 50 years. It offers a wide variety of features. Laser engraved thread size, Blue Wave logo, and side marking of the left thread.
|
|
|
The Blue Wave Chromed Bronze Body features a number of details that makes it the best choice for exclusive and durable rigging. The sleek, open Bronze body prevents the threads from seizing up, they are delivered with laser engraved thread size, Blue Wave logo, and side marking of the left thread.
|
|
|
|
