MR 16 Adjustable Downlights
This exterior adjustable downlight has been installed on many yachts and is designed for exterior use.
Application: Exterior overheads
Lens: Clear or frosted
Type of bulb: M16 Halogen lamp. Maximum 50 watts
Power Supply: 12/24 Volt or 120/230 Volt with an external transformer
Bezel Material: Polished stainless steel
|
|
Recessed spotlights fitted with power-LEDs from 1.0 to 2.5W. Similar to the Minispots, they have an airtight body on which to attach a wide array of fittings.
The remarkable lighting intensity distributed at a 70° emission angle makes them ideal for lighting small areas or specific internal and external zones.
Also in this case the fitting can be custom designed. Internal electronics with a power supply from 10 to 30 Vdc.
|
|
Recessed spotlights fitted with power-LEDs from 1.0 to 2.5W. Similar to the Minispots, they have an airtight body on which to attach a wide array of fittings.
The remarkable lighting intensity distributed at a 70° emission angle makes them ideal for lighting small areas or specific internal and external zones.
Also in this case the fitting can be custom designed. Internal electronics with a power supply from 10 to 30 Vdc.
|
|
Recessed LED downlight, emitting direct and concentrated light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
170 Lumen
Lighting Beam: 50°
ELECTRICAL DETAILS:
PowerLED 6W@10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed LED downlight, emitting direct light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
ELECTRICAL DETAILS:
PowerLED 10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed LED downlight, emitting direct and concentrated light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k or Natural White 3700°k
Cri: 97%
250 Lumen
Lighting Beam: 40°
ELECTRICAL DETAILS:
PowerLED 12W@20-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed LED downlight, emitting direct light, suitable for any environment.
Antidazzling built-inrefl ector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
ELECTRICAL DETAILS:
PowerLED 10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed fixture, emitting direct and diffused light, suitable for any environment.
Stainless steel AISI 316 trim ring available in polished finishing.
|
|
|
Recessed fixture, emitting direct and diffused light, suitable for any environment. Stainless steel AISI 316 trim ring available in either polished or lacquered or matt nickel or 24k gold finishings.
|
|
Recessed LED downlight, emitting direct and diffused light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
285 Lumen
Lighting Beam: 90°
ELECTRICAL DETAILS:
PowerLED 12W@10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed LED downlight, emitting direct and diffused light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
285 Lumen
Lighting Beam: 90°
ELECTRICAL DETAILS:
PowerLED 12W@10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
Recessed LED downlight, emitting direct and concentrated light, suitable for any environment.
Antidazzling built-in reflector and circuits on board.
FOR INTERIORS AND EXTERIORS
PROTECTION GRADE IP65
MULTIVOLTAGE DRIVER ON BOARD
DIMMABLE THROUGH DIMMER CLL
LIGHTING DETAILS:
PowerLED Warm White 3000°k
Cri: 80%
170 Lumen
Lighting Beam: 50°
ELECTRICAL DETAILS:
PowerLED 6W@10-30Vdc
Installation 2 wires in parallel
Polarity reversal protected
|
|
|
Lumitec's new Flush Mount Down Lights set a new standard in overhead lighting. The luminaires feature weatherproof construction suitable for interior or exterior installations, a shallow-depth profile (less than ½" below mounting surface) and an easy to install mounting system. Ideal for salons and staterooms, as well as helm stations, flybridges and hard tops. The lights are fully sealed and IP67 compliant. Intelligent circuitry enables advanced features like dimming and four-color control without external control modules or specialized switches. This allows boat owners to use any existing "on-off" switches and eliminates the need for multiple wire runs necessary for other multi-colored lights. Light output options include 4-color (white/red/blue/purple), red/white with dimming, blue/white with dimming and white only. 10 to 30VDC, draws 220mA @ 12V, 110mA @ 24V.
|
|
|
Lumitec’s new flush mount down lights set a new standard in overhead lighting. The luminaires feature weatherproof construction suitable for interior or exterior installations, a shallow-depth profile (less than ½” below mounting surface), and an easy to install mounting system. Ideal for salons and staterooms, as well as helm stations, flybridges and hard tops, the lights are fully sealed and IP67 compliant. Intelligent circuitry enables advanced features like dimming and four-color control without external control modules or specialized switches. This allows boat owners to use any existing “on-off” switches and eliminates the need for multiple wire runs for multi-colored lights. Light output options include 4-color (white/red/blue/purple), red / white with dimming, blue/white with dimming, and white only. 10 to 30VDC, draws 220mA @ 12V, 110mA @ 24V.
|
|
|
|
|
|
|
The 2009 Boat Show season hails the launch of Liet, a revolutionary interior and exterior lighting range. These LED Liets are the most forward thinking lights of our generation. For example, the larger Liet6 (as shown here) produces the equivalent light output of a GU10 50w Halogen.
Liet is the world’s most highly advanced, intelligent, high output LED light. It’s polymer body is a stunning, wafer thin 9mm (3/8”); yet incorporates all it’s electronic driver circuitry comprising of a full on-board 0-10v dimming system compatible with all known control systems; a complete self-diagnostic fault indication system surrounded by precision optics over each LED. In the Liet6, the high power LED's consume a miniscule 5.3w in total, yet deliver a massive 584 Lumens in the first stage output prior to secondary stage collimated magnification via T.I.R. (total internal reflection), boosting peak intensity by over 500%. Due to it’s innovative design Liet6 is up to 10x brighter than the best of the leading competition.
With the coveted correct colour temperature, perfect evenness of light spread and the immense light output of Liet, 100% LED lighting is now a reality. Massive reductions in areas such as cable weight, power consumption and heat emissions, will mean smaller A/C units, smaller onboard generators and lower fuel requirements which will ultimately lead to more efficient yachts.
|
|
|
|
|
|
|
The 2009 Boat Show season hails the launch of Liet, a revolutionary interior and exterior lighting range. These LED Liets are the most forward thinking lights of our generation. For example, the larger Liet6 (as shown here) produces the equivalent light output of a GU10 50w Halogen.
Liet is the world’s most highly advanced, intelligent, high output LED light. It’s polymer body is a stunning, wafer thin 9mm (3/8”); yet incorporates all it’s electronic driver circuitry comprising of a full on-board 0-10v dimming system compatible with all known control systems; a complete self-diagnostic fault indication system surrounded by precision optics over each LED. In the Liet6, the high power LED's consume a miniscule 5.3w in total, yet deliver a massive 584 Lumens in the first stage output prior to secondary stage collimated magnification via T.I.R. (total internal reflection), boosting peak intensity by over 500%. Due to it’s innovative design Liet6 is up to 10x brighter than the best of the leading competition.
With the coveted correct colour temperature, perfect evenness of light spread and the immense light output of Liet, 100% LED lighting is now a reality. Massive reductions in areas such as cable weight, power consumption and heat emissions, will mean smaller A/C units, smaller onboard generators and lower fuel requirements which will ultimately lead to more efficient yachts.
|
|
Sizes: 100mm
Weight: 381g
Voltage: 12v/ 24v or 130v/ 230v
Wattage: 5w/ 10w/ 20w or 25w/ 40w or LED
Lamp Type: G4 or G9 or LED
IP Rating: 66 as Standard with all Exterior Lights
Lenses:
Sandblasted
Dichroic Coloured Mirror
Clear
Additional information:
Light Outputs
|
|
|
Revolutionary 10w LED Lighting brighter than 20w Halogen but providing the same warm light output, taking away the ghosting effect usually associated with LED, whilst no compromising on light output, completely dimmable call our sales team today for a free demonstration.
|
|
The Fixed-Single 1 watt LED (Ref. S40211-SS-*) with screwed 316 Stainless Steel polished bezel and 1 meter of cable.
The LED is available in two white colours, warm (W) or cool (C), and red (R), green (G) and blue (B)
The front bezel is IP 68 and the rear part of the lamp is IP 44.
One Driver (S41104) is required to power seven Single 1 watt LED’s.
|
|
Powerful recessed spotlights with reduced dimensions. They consist of an airtight lamp available either in white light (hot or cold) or RGB (colour-changer), on which to attach fittings that comes in various solutions that can also be custom designed on request.
Internal electronics with a power supply of 10 to 30 Vdc.
|
|
Powerful recessed spotlights with reduced dimensions. They consist of an airtight lamp available either in white light (hot or cold) or RGB (colour-changer), on which to attach fittings that comes in various solutions that can also be custom designed on request.
Internal electronics with a power supply of 10 to 30 Vdc.
|
|
Powerful recessed spotlights with reduced dimensions. They consist of an airtight lamp available either in white light (hot or cold) or RGB (colour-changer), on which to attach fittings that comes in various solutions that can also be custom designed on request.
Internal electronics with a power supply of 10 to 30 Vdc.
|
|
The Single LED Eyeball (Ref. S40154-SS-*) with screwed 316 Stainless Steel polished bezel and 1 meter of cable.
The LED is available in two white colours, warm (W) or cool (C), and red (R), green (G) and blue (B).
The front bezel is IP 68 and the rear part of the lamp is IP 44.
The eyeball of the LED can be adjustable.
One Driver (S41104) is required to power seven Single 1 watt LED eyeballs.
|
|
|
This line of Lumitec's accent/courtesy lights are compact, attractive, surprisingly bright . Choose white, red, or blue light output to illuminate counters, stairs, companionways. Completely sealed and IP67 compliant, these lights are also suitable for cockpits, hardtops, or illuminating helm stations. 30mA @ 12VDC.
|
|
Built with the same quality and reliability as our underwater lights,
our LED overhead and courtesy lamps are made out of marine grade stainless steel or anodized aluminum and are watertight.
Extremely compact and extremely bright
|
|
|
|
