Providing a healthy complement to other marine safety equipment, the Firehouse is a smart choice for any marina. Standard on the Firehouse are a night light to illuminate the marine dock and surrounding area, an alarm for boats strobe light with siren, and a fire extinguisher. An optional 24" life marine ring is available. An innovative feature optional with the Firehouse is a remote control for boat unit that automatically calls selected services when the alarm has been activated. The four-channel transmitter can call medical, fire, police, and general emergency services. Don't get caught off guard in the event of a dangerous situation; equip your Marina with the Firehouse and be prepared.
Main Features include:
13 watt photocell controlled fluorescent night light to illuminate dock and the fire extinguisher area
Alarm strobe light and siren are automatically activated when door for boat is open or an optional life ring is removed
A 10 lb. ABC type fire extinguisher located in each cabinet
Easy access to fire extinguisher through a hinged clear polycarbonate door
Aluminum housing with oven-baked enamel finish with polycarbonate base and top
Optional 24" life ring
Optional remote control unit automatically calls selected emergency services |
|
| Marine Technologies Fire station is the first fire storage system to incorporate advanced security and communication features. The Fire Station offers an effective deterrent to fire extinguisher theft and advanced alarm for boats signalling. |
|
| The details count. The expertise of Poralu Marine is not limited to the manufacturing and installation of your marina. We offer a wide range of services and products to provide a maximum level of comfort to your customers. You can choose your service marine bollards, fuel and pump for boats out stations, combining accessories such as handrails, ladders for boats, boxes, marine cranes, berth number tags etc... |
|
| The TallyKey T6 SOS-pedestal is a perfect supplement to an existing TallyKey installation, or it can be used stand-alone for situations, where only SOS-points are required. As standard, the T6 SOS is prepared for both fire extinguisher and life marine buoy, and as an option a low-energi T6 style sailboat lamp can be fitted at the top. |
|
Electro-Tec offer a large range of Fire & Saftey marine equipment including, life rings for boats, fire fighting equipment. We also manufacture our own range of SOS Pedestals which can incorporate the following equipment:
Boat fire extinguishers
Hand Axe
Marine first aid kit
Floating Line
Life Ring
Audible and Visual Alarm for boats System
High level Illuminated SOS Sign
Firefighting Hose and Nozzle
The Electro-Tec SOS boat pedestal is manufactured from the same highly durable composite materials as used in our leading Power Pedestal Range.
|
|
One of the most important roles of any marina operator is the safety of the customer. Rolec now offers its most comprehensive range of marina emergency service marine equipment ever, including:
- Emergency pedestals across the Classic, Spinnaker and Ocean ranges
- Economy emergency cabinets Mobile fire fighting caddy Life marine buoy stands
- Boat fire extinguishers in housings and on wheeled trolleys Fire hydrants
- Alarm for boats call points |
|
BORNEO RANGE
made of TECK
IP56 enclosure
lighting for boat (LED low power)
water in option
up to 4 electric sockets |
|
HDPE CABINET - STAINLESS STEEL MODEL
Service pedestals equipped with prepaid and/or consumption metered system are activated by a transponder, that is a contactless key, programmed by the manager by means of suitable decoder. This key is handed over to the customer at his arrival.
The centralized computation, that needs connection cables to the office, and the prepaid system can coexist in the same service marine pedestal.
By means of a directional transponder the marina manager can visualize on the service pedestal display the consumptions of energy and water for local computation.
TECHNICAL CHARACTERISTICS
Module:Built in compliance with CE and IEC 364-7-709
Protection class: IP 67
Cabinet:HDPE UV protection (250x350x800h mm) –
Stainlees steel AISI 316 L (170x250x750h mm)
Interlocked sockets:16A to 125A
Protections:Id 30mA – Main switch
Cable connection:3P+N+E – input/output 16 mm² to 300 mm²
Water supply:½” ball valve tap
Lighting for boats:9W low-consumption florescent boat lamp
Electricity meter:Progressive electricity meter. Display kW/h consumption for each socket
Water meter:Liter-counter and display of progressive metering of each output
Pre-paid system on transponder
Communication:Intercom system
Connections:IP 67 Module, TV-SAT, Telephone, Internet
|
|
Marine Technologies are proud to introduce our new boat pedestal…..The Sterling.
Smaller berths on marinas don’t generally require the extent of services necessary for larger berths. With this in mind, Marine Technologies has introduced a new pedestal to the market. “The Sterling” meets the needs of smaller berths perfectly and is offered without compromising quality.
• Unique slimline design makes it ideal for installing along walkways and marine gangways.
• Can fit up to six outlets in combination from 16A single phase to 3 phase outlets up to 32A.
• Specifically designed light for marina applications with a hinged top means no loose parts to fall into the marina when replacing boat lamps. Surrounding louvres direct light downwards toward the marina decking.
• The main body of the pedestal is anodised, extruded aluminium and has a slide out panel for boat for easy access during maintenance.
Marine Technologies Sterling pedestal is a most economical solution whilst still maintaining Marine Technologies high standard of quality. |
|
Modern Marinas are designed to last well over 25 years, however most service pedestals built from galvanised steel or plastic will need replacing well before that. The integral strength in the M-Tech marine pedestal is aluminium and stainless steel, a combination which will outlast any other material used in the construction of service pedestals.
Should damage occur from collision with vessels, the M-Tech pedestals are very easy to repair.
Our pedestals are tailor made to the individual requirements of the marina operator and can be fitted with single and /or three phase power, water and electricity metering,
Photo-electric cells to switch for boat the units on and off, phone for boats / data outlets, lockable boat doors, weatherproof marine speakers and electrolysis blockers.
MP1100
Two tone grey.
Many other colour combinations avaliable.
|
|
Modern Marinas are designed to last well over 25 years, however most service pedestals built from galvanised steel or plastic will need replacing well before that. The integral strength in the M-Tech marine pedestal is aluminium and stainless steel, a combination which will outlast any other material used in the construction of service pedestals.
Should damage occur from collision with vessels, the M-Tech pedestals are very easy to repair.
Our pedestals are tailor made to the individual requirements of the marina operator and can be fitted with single and /or three phase power, water and electricity metering,
Photo-electric cells to switch for boats the units on and off, phone for boat / data outlets, lockable marine doors, weatherproof boat speakers and electrolysis blockers.
Two tone grey.
Many other colour combinations avaliable.
MP800XL |
|
| The details count. The expertise of Poralu Marine is not limited to the manufacturing and installation of your marina. We offer a wide range of services and products to provide a maximum level of comfort to your customers. You can choose your service marine bollards, fuel and pump for boat out stations, combining accessories such as handrails, boat ladders, boxes, marine cranes, berth number tags etc... |
|
TallyKey's pedestals are made exclusively of quality materials, ensuring a long working life.
The boat pedestal itself is made of aluminium, while bolts, shafts and screws are in stainless steel.
If the pedestal has a sailboat lamp in the top, the "glass" is made of impact-resistant plastic.
The TallyKey T2 pedestal is thus strongly equipped to survive many years of outdoor use, even in the harsh and aggressive environment at a boat harbour.
A carefully thought-out detail is the special safety washers with which the base is mounted. If a pedestal is bumped or a boat departs from land and has forgotten to uncouple from the pedestal, the safety washers are broken first - the pedestal itself suffers no damage and it can be remounted immediately with new safety washers.
|
|
The ESB Marina Power Boat pedestal, in all of its variations has been designed with the intention of being the most versitile and dynamic Power Pedestal on the market.
With the capacity to accomodate most servicers the ESB is provings its thoughtful and innovative design is fulfilling the requirements of marina operators and users worldwide.
The ESB is supplied as standard with top for boats mounted light with the option of either enegery saving marine lamps or up to 15 year life span L.E.D. lighting for boats technology .
The ESB is also supplied as standard with our 4mm Composite Material. This material is incredibly durable and highly resistant to UV Fading. |
|
The ESB Marina Power Marine pedestal, in all of its variations has been designed with the intention of being the most versitile and dynamic Power Pedestal on the market.
With the capacity to accomodate most servicers the ESB is provings its thoughtful and innovative design is fulfilling the requirements of marina operators and users worldwide.
The ESB is supplied as standard with top mounted light with the option of either enegery saving marine lamps or up to 15 year life span L.E.D. lighting for boats technology .
The ESB is also supplied as standard with our 4mm Composite Material. This material is incredibly durable and highly resistant to UV Fading. |
|
The ESB Marina Power Marine pedestal, in all of its variations has been designed with the intention of being the most versitile and dynamic Power Pedestal on the market.
With the capacity to accomodate most servicers the ESB is provings its thoughtful and innovative design is fulfilling the requirements of marina operators and users worldwide.
The ESB is supplied as standard with top for boats mounted light with the option of either enegery saving marine lamps or up to 15 year life span L.E.D. lighting for boat technology .
The ESB is also supplied as standard with our 4mm Composite Material. This material is incredibly durable and highly resistant to UV Fading. More Information can be found here. |
|
The VX Marine pedestal is our newest range and was launched at the 2007 Dubai International Boat show. Designed to be the ultimate in durablity and longevity, the VX Range is manufactured from the toughest materials and supplied with L.E.D. Lighting for boat as standard.
L.E.D. Lighting not only consumes up to 85% less electricity, it will last up to 15 years making regular sailboat lamp replacements a thing of the past!
The streamlined design of the VX pedestal offers a unique appearance intended to compliment modern developments. The curved exterior conceals a hidden sliding door for boat system which provides access to circuit breakers and metering marine equipment. The angled lighting diffuser is designed to illuminate both the electrical equipment and the immediate enviroment. |
|
The ESB Marina Power Boat pedestal, in all of its variations has been designed with the intention of being the most versitile and dynamic Power Pedestal on the market.
With the capacity to accomodate most servicers the ESB is provings its thoughtful and innovative design is fulfilling the requirements of marina operators and users worldwide.
The ESB is supplied as standard with top for boats mounted light for boats with the option of either enegery saving boat lamps or up to 15 year life span L.E.D. lighting for boat technology .
The ESB is also supplied as standard with our 4mm Composite Material. This material is incredibly durable and highly resistant to UV Fading. |
|
The ESB Marina Power Boat pedestal, in all of its variations has been designed with the intention of being the most versitile and dynamic Power Pedestal on the market.
With the capacity to accomodate most servicers the ESB is provings its thoughtful and innovative design is fulfilling the requirements of marina operators and users worldwide.
The ESB is supplied as standard with top for boats mounted light with the option of either enegery saving boat lamps or up to 15 year life span L.E.D. lighting for boats technology .
The ESB is also supplied as standard with our 4mm Composite Material. This material is incredibly durable and highly resistant to UV Fading |
|
| The Roline Range is manufactured in heavy-duty aluminium and powder coated to a colour or colours of your choice with stainless steel upgrade versions available upon request. The Roline unit can be equipped with single or three phase electrical sockets complete with overload and fault current protection, as well as low-level pontoon-facing illumination. |
|
| Rolec has the largest range of super yatch services available in the marina services industry. This Maxi Classic bollard is the perfect answer to providing services to a boat that demands everything. The Maxi can offer services up to 400amp three phase complete with water supplies up to 2", with either aluminium or stainless steel bodies. It can cope with every demand. Add TV, telephone and illumination and the Maxi offers your berths a complete service. |
|
| Card Meters are one option for the marina operator to recover money for electricity consumed in 'pre-pay' rather than credit format. The reconditioned Card Meters are accessed through customer reset flaps. A card is purchased with a pre-determined value loaded onto it which, when inserted into the meter, loads that value onto the meter. The meter then counts down the pre-loaded value until it is consumed. An emergency credit value of £1.00 is available on each meter. Alterations to the tariff / emergency credit value can be made by the use of a Meterman card. |
|
Electro-Tec have recently released our new range of coin controlled services. The CSP (Controlled Service Boat pedestal) uses the latest technology to electronically control services. The CSP has the following features:
*Coin control using £ or € in almost any denomination.
*Coin collected tray manufactured from heavy duty stainless steel for secuirty.
*Users insert coin and select service using the relevant button above each service
*Once credit is activated the CSP dispensers the required amount of power or water, for example this could be 1KW of Electricity or 100L of Water.
*When the above values have been reached, the system automatically cuts off the supply.
*Services can be dispensed in eather quantity (KW or Litres) or Time (E.G. 10 Minutes)
*Admin Mode - With the use of a master key, the marina can reset the credit to zero or even change the mode of the CSP to give free electricity or water
*Easy to reprogram, no expensive programming tools needed! - To re-program the CSP is incredibly simple. Simply send the required values you wish to change (E.G. change from 1KW to 2KW) to Electro-Tec and we will send you a MEMORY CARD which simply inserts into the pedestal control module. Once inserted, the pedestal automatically loads the new program and activates it.
*Highly reliable - Using the latest technology developed by Siemens the CSP is incredibly reliable.
*Future updates - We will soon be releasing a new version of the CSP with a backlit display marine screen. This screen can provide instructions on the units use and count down the available credit. |
|
One of our most popular units, the all-purpose Lighthouse boat pedestal has a wide range of features.
With units in service around the world, this stylish power pedestal is recognized for its practicality and exceptional durability.
Available with Digital Electronic Metering (One, Two or Three Element Meters Available) |
|
PHOCEA RANGE
distribution of water and electricity (4 sockets max)
structure made of polyester armed fiberglass
integrated lighting for boat
differential breaker 30mA
energy control in option
colour in option
ELECTRIC METER IN OPTION
WATER METER IN OPTION |
|
DM2I/DM4I Metered Option
Two or Four Way Marine bollards with the metering option. A range of meters can be supplied from the 100A rated Ofgem Approved meter primarily used in the two way unit to the din rail mounted single module 32A rated version utilised in the four way unit. Computerised metering and energy control can also be provided and an alternative brochure covering this option is available upon request. Illumination is provided by means of 2D 16 control gear and sailboat lamp along with a 6A Single Pole MCB and P12R Photocell. |
|
|
