- Divide your consumption by 10 !
- Very high efficiency LED lamp
- Very long life: >50,000h (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Power consumption: 1W typ.
- Current draw: <90mA @ 12VDC / <45mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 300° horizontal / 120° vertical
- Dimensions: Ø 0.79"
- Available in lengths: 1.42" / 1.5" / 1.62"
- Pictures and information may be changed or updated without notice
|
|
- Divide your consumption by 20 !
- Very high efficiency LED lamp
- Very long life: >50,000h @ 25°C (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Very low power consumption: 1.8W typ.
- Current draw: <150mA @ 12VDC / <80mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 360° horizontal / 120° vertical
- Dimensions: Ø 1" x 2.3"
- Available with BA-15S or BA-15D or BAY-15D bayonet base
|
|
As an indication, a traditional bulb of 10-15 W replaces
16 led under plastic sphere
Lighting = WHITE 360°
Consumption = 1,8 W
Illumination = 32 lumens
Tension = 24 V cd.
Detailed description:
Total height bulb = 53 mm
Diameter bulb = 24,5 mm
Diameter base = 15 mm
Height base = 20 mm
Contacts = 2
Pins = shifted
Reference: 04BAY15D16-24
|
|
|
|
