Working load: 1 t - 50 t
... . When the space is limited capstans are widely preferred due to dimensions. Vertical windlass and capstans with pull capacity of 1 tonnes upto 50 tonnes, are suitable for chain size between 12-81 mm. ...
Working load: 1 t - 10 t
YMV capstans and vertical windlasses main properties: -Pull Capacity: 1-10 t -Suitable for Chain Diameter: 12 -46 mm -Electric or Hydraulic Drive -Manual Operated Clutch and Band Brake Optional ...
Working load: 5000, 4600, 4700 kg
Stainless steel capstan winch, with different drives and recommended for boats up to 50 m (Milos Plus). Possibility of 24V, 230V, 400V or hydraulic drive.
Working load: 4700, 5000, 4600, 5200 kg
Stainless steel capstan winch, with different drives and recommended for boats up to 50m. Possibility of 24V, 230V, 400V or hydraulic drive.
Working load: 4000, 4500, 2000 kg
Steel capstan winch, with different drives and recommended for boats up to 38 m (Milos Plus). Possibility of 230V, 400V or hydraulic drive.
Working load: 5637 kg - 11550 kg
Stainless steel capstan winch, with different drives and recommended for boats up to 60 m. Possibility of 230V, 400V or hydraulic drive.
Description Capstan winch is designed for warping rope. Technical data: Models: VPV0,7-K1H; VPV1,0-K1H; VPV1,3-K1H - drum torque M = 0,7 to 1,3 kNm - drum speed revolution n = 31 rpm - pulling force (1. layer) F = 8 to ...
... Warping head • FWD REV push button control (shipped loose) • 25 Hp Electric drive brake motor with failsafe brake • FVR Starter for 25 Hp (shipped loose) Options: • Dual speeds • Hydraulic drive motor
Designed to suit vessels up to 26m (84ft) the Muir range of capstans provide reliable and heavy duty operation for mooring, warping and anchoring for all recreational and commercial applications. Efficient and quick they ...
Rondal has developed a modern take on the traditional spoke-driven capstan for tall ship projects. Built from stainless steel and hydraulically driven, the capstans nevertheless retain fully authentic ...
- with electric drive - with hydraulic drive Load [kN] from 30 to 50 Size [mm] from 17 to 36
Ibercisa designs and manufacture electric and hydraulic driven capstans for all work vessels. IBERCISA Capstans winches include: - Hydraulic or Electric ...
... or via an internal combustion engine. Features of Marine Capstan: 1. This capstan can adopt electric or hydraulic drive. 2. Configurations are vertically mounted. 3. ...
Features: -Electric, hydraulic or air powered -Variety of control options -Failsafe drive train braking system -AISI 316 stainless fasteners (3/4” dia. & smaller) -Zinc-plated graded fasteners -Monel grease fittings -Continuous ...
Electric or hydraulic driven. The BCM capstans can be directly incorporated into the deck structure with easily connection for motors from below deck.
Spencer Carter Capstan Haulers are robust machines designed for professional use in arduous conditions. They can be used for any rope hauling application, anchor handling etc. CCA Compact Aluminium Capstan ...
DATA offers capstans with pull starting from 500 kgs up to 11000 kgs. They are designed with gears and motors below the deck for an uncluttered on deck.
Rapp Marine builds electric and hydraulic driven capstans for all work vessels
Features: - Vertical thru-deck or above deck models. - Fabricated steel construction. - Polished steel capstan head. - Head size to 36" diameter. - Single or variable speeds available. - Line pull up to 10,000 ...
The CYP-80 is a rugged hydraulic capstan available as a single-speed or dual-speed unit. Each features proportional hydraulic valve control (direction and speed), a low-maintenance design, ...
Working load: 3 t - 8 t
CHARACTERISTICS Operation: Electric or hydraulic Capacity: Pull from 3 to 8 tons Wire rope capacity: From 5,000 to 8,000 m Configuration: With or without guide Control: Local or remote
Working load: 3 t - 25 t
CHARACTERISTICS Operation: Electric or hydraulic Capacity: Pull from 3 to 25 tons Speed: Up to 30 m/min Type: Vertical or horizontal Configuration: Drum for rope/steel wire rope Control: Local or remote
Capstans from 3 up to 30 ton The motor can be located: on deck/under deck The capstans can be equipped with hydraulic or electric drive, with or without inverter. On ...
The 22300 thru-the-deck capstan from Schoellhorn-Albrecht has been the trusted capstan for barge moving, buoy handling, and general line handling by U.S.C.G., U.S.A.C.E., and commercial shipyards worldwide. ...
Schoellhorn-Albrecht's SA1014 capstan/carpuller model is used for everything from the railroad industry to barges and the variety of options allow you to find the one to meet your needs. Features: . Cast Steel Capstan ...
Hydraulic Muir/Cramm capstans Hydraulic capstans are produced vertically in high-gloss polished stainless steel and have a tensile strength of 82,000 N.
How to choose this product
A hydraulic capstan is a mechanical device consisting of a vertical drum powered by a hydraulic motor. The rotating drum is used to handle hawsers and mooring lines of a ship or a yacht. It differs from a windlass in that it is vertical and has no wildcat or gypsy, the indented wheel designed to hold the links of an anchor chain.
This equipment is found on all types of vessel where mooring lines are too heavy for manual handling, generally ships and large yachts.
The capstan drum usually rotates around a vertical shaft. On yachts, the motor is often hidden under the deck, while on ships it sits on deck, beneath the drum. It may use a vessel's central hydraulic system or be fitted with its own.
Some have variable speed, for both slow, precise maneuvers and rapid line handling in emergency situations. Yacht models usually have cleaner, more carefully conceived lines than those found on merchant vessels.
How to choose
Choice will depend on the capstan's size, its location on deck and the diameter of the line or chain to be handled.
