Coelmo Marine® Generator model DM350, 3,2 kW Cont. 3,5kW Max, 50Hz, rated voltage 230V, equipped with:
- Engine Farymann type 18W, diesel monocylinder 3000 rpm/min;
- Alternator COELMO C35, synchronous, brushless, self excited, self ventilated, insulation class H;
- Sea water cooling system for engine and alternator;
- Remote command and control board EOS®;
- Sound proof canopy 52 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 590x405x515H
Weight Kg: 105
|
|
Generator Coelmo Marine® model DML970 da 7,4kW, 50Hz, rated voltage 230V, equipped with:
- Engine Kubota type V1505-BG, diesel four cylinders 1500 rpm;
- Altenator Mecc-Alte sinchronous, self excited, self ventilated, insulation class H;
- Cooling system through heat exchanger;
- Command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 1100x650x790H
Weight Kg: 310
|
|
Generator Coelmo Marine® model DML740 da 7,4kW, 50Hz, rated voltage 230V, equipped with:
- Engine Kubota type D1105BG, diesel three cylinders 1500 rpm;
- Altenator Mecc-Alte sinchronous, self excited, self ventilated, insulation class H;
- Cooling system through heat exchanger;
- Command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 950x540x755H
Weight Kg: 280
|
|
Coelmo Marine® Generator model DM600, 5,5 kW Cont. 6kW Max, 50Hz, rated voltage 230V, equipped with:
- Engine Nanni Diesel type N2.10, diesel bi-cylinder 3000 rpm/min;
- Alternator COELMO C60, synchronous, brushless, self excited, self ventilated, insulation class H;
- Cooling system with heat exchanger;
- Remote command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 650x480x530H
Weight Kg: 128
|
|
Generator Coelmo Marine® model DTL2590 da 20,7kW, 50Hz, threephase rated voltage 230V, equipped with:
- Engine Kubota type V2403-M, diesel four cylinders 1500 rpm;
- Altenator Mecc-Alte sinchronous, self excited, self ventilated, insulation class H;
- Cooling system through heat exchanger;
- Command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 1250x600x790H
Weight Kg: 450
|
|
Generator Coelmo Marine® model DML1330 da 13,3kW, 50Hz, single phase, rated voltage 230V, equipped with:
- Engine Kubota type D1703-BG, diesel four cylinders 1500 rpm;
- Altenator Mecc-Alte sinchronous, self excited, self ventilated, insulation class H;
- Cooling system through heat exchanger;
- Command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 1100x650x790H
Weight Kg: 430
|
|
Generator Coelmo Marine® model DTL3290 25,6kW, 50Hz, threephase rated voltage 230V, equipped with:
- Engine Kubota type V3300-BG, diesel four cylinders 1500 rpm;
- Altenator Mecc-Alte sinchronous, self excited, self ventilated, insulation class H;
- Cooling system through heat exchanger;
- Command and control board EOS®;
- Sound proof canopy 54 dB(A) at 7 meters completely marine aluminium made.
Dimension mm: 1590x700x900H
Weight Kg: 710
|
|
|
|
|
|
|
AC Generating Sets 3 to 50kVA
Beta Marine Generating Set having Continuous Rated Outputs, and operating at 0.8 PF, 50Hz or 60Hz; designed, built and tested by BETA MARINE Limited.
•Beta Marine Kubota water cooled diesel engine, naturally aspirated, rated for continuous operation in accordance with ISO 3046 (BV3300T is turbocharged). An overload of 10% is available for one hour during 12.
•Heat exchanger cooling with fresh water and sea water pumps; water cooled exhaust manifold and water injection exhaust bend.
•12 volt electric start system with a combined start, alarm and shutdown module.
•Marine rated generator operating at 0.8pf, and 50 Hz, single bearing construction, complete with terminal box, automatic voltage regulator, mounted on substantial steel feet with marine failsafe anti-vibration mountings.
•Each generating set is “full load” tested with a 12 months Warranty from date of commissioning.
•Keel/box cooling versions are available
Acoustically Housed Generating Sets - Based upon our Standard Generating set but housed in an Acoustic Canopy – the noise level will be less than 60dB(A) sound pressure when measured at 7 metres under “free field” conditions. All generating set connections are brought out of the housing for quick and easy installation.
|
|
Marine Power 30 to 900kVA
Beta Marine produce marine generating sets to customer’s specific requirements, including Classification Societies: Lloyds Register of Shipping, Det Norske Veritas, Bureau Veritas, Germanisher Lloyd, ABS etc.
We can offer: Cummins, Caterpillar, Perkins, Volvo, Scania, MAN, MTU marine diesel engines with heat exchanger (or keel or radiator) cooling, coupled to Newage “Stamford” or Mecc Alte marine rated alternators.
Beta Marine’s considerable experience in building: Main; Emergency and Harbour Generating Sets for different applications: passenger ferries, cargo boats, fast patrol boats, gas carriers, fishing trawlers, tugs and “super yachts” has been used in the development of these generating sets from 30kVA up to 900kVA. We can also supply generating sets in Acoustic housings designed to customer specifications.
|
|
|
|
|
|
|
Fischer Panda 4000i: The energy pack – quiet, small and light
Inverter technology features more performance with less weight onboard.
Fischer Panda has developed a genuine innovation of power supply onboard with the new Panda 4000i. The permanent magnet generator with its inverter technology is capable of producing a continuous supply of 230 V at 50 Hz – at a lower speed of just 2800 U/min. Currently in development, the ability to reduce the speed by a further 20% if the consumption reduces.
Thus the Panda 4000i is clearly quieter and smaller than comparable generators of conventional design. Also the weight with only 88 kilograms turns out to be around a quarter less - which is an important argument for the use on yachts.
The Panda 4000i is a reliable energy pack with four kilowatts which also supplies large consumers on board. It has enough power to reliably start and operate a Bauer Junior diving compressor with a capacity of 2.2 kilowatts. For this reason, the Panda 4000i with 12 per cent higher performance than a conventional generator is the champion in its generator class.
With the Panda 4000i the new inverter technology comes on board which unlike otherwise only appears in military applications. With the new Panda 4000i in hall 8, booth A 21, Fischer Panda shows once again that it is leading the way with innovation and technology
Fischer Panda – Power wherever you are
|
|
|
The Panda generator NE version has been fitted for many years with the tried and tested VCS (Voltage Control System) whereby the motor speed is progressively controlled. This has an enormously positive effect on the exhaust emission and ensures that the generator achieves up to 15 % more effective performance than other non-controlled generators. The VCS adjusts the voltage with a tolerance of +/- 3 volts in the range up to 80 % of the nominal performance. An external AC control box contains the VCS and the capacitors which are used for boosting the starting current. This is standard for models from Panda 4500 SCB/FCB and 5000 LPE up to 18NE.
|
|
The innovative new Fischer Panda 6000i Generator uses variable speed technology which allows the speed of the engine to be regulated and adjusted according to the electrical load that is connected. The high starting performance for inductive load makes the generator ideal for starting an air conditioning unit or even running a diving compressor. The clean sinus wave form with its accurate voltage and frequency regulation ensures that a stabile and efficient supply of power is available for sensitive electronic devices.
A new control panel and engine controller have been designed by Fischer Panda for this generator technology. The control panel allows the generator to be operated from the cabin and displays current status and technical data. The new panel is compact so it can be installed on small dashboards. The low weight (116kg) and compact size (LxWxH : 550x440x530) allows the generator to be installed in very tight spaces.
|
|
The Fischer Panda innovative and integrated energy systems provide on-board power for vehicles and marine vessels without the requirement to have a permanently running generator. The extremely robust AGT generators have proven their reliability under extremely adverse conditions. Concerns about an independent power supplies and empty batteries are impressively solved using this Fischer Panda technology. The 75 lifeboats of the Royal Navy Lifeboat Institute are a great example of
their reliability. These boats which are equipped with Fischer Panda AGT generators, have been operating problem-free since 1997.
AGT - The advantages
Longer lifespan for generator
Reduced maintenance costs
Reduced environmental pollution
Reduced exhaust emissions
Reduced fuel consumption
Less noise onboard and outside
Smaller battery bank possible
Up to 30 % smaller and lighter
Automatic start is standard (AGT 4000) or
optional
Dual-circuit cooling is standard all AGT
generators
|
|
The new Panda 4000s generator model is based on the successful 1-cylinder Farymann engine series, which is already in use with Fischer Panda Generators. The generator offers a diverse range of improvements - such as increased starting current for inductive consumers, pure sinus wave, easier installation, and reduced maintenance costs. The generator is available with sea water cooling or with indirect freshwater cooling using a heat exchanger.
- 230 V / 50 Hz.
For your complete on-board power system
- High starting capacity. Perfect for running a diving compressor or air conditioner
- Extremely compact and light . More room for other things
- Super silent sound insulation capsule. You can relax while the generator runs
- Innovative Design. Easy to install and maintain
- Improved performance. Integrated fuel pump and voltage stability
|
|
Northen Lights continues to set the industry standard for marine power generation. Our latest innovation is the 99kW (60 Hz) M1066TMCA. This is the first radiator-cooled generator set to carry not only the Northern Lights legacy for quality, but is MCA-approved for the yacht market.
The M1066TMCA features Northern Lights’ industry-proven inline six cylinder design, providing single side servicing on a sturdy, industrial engine block. Northern Lights’ custom marinization process makes for a solid power package, able to log long hours with routine maintenance.
The M1066TMCA’s revolutionary design makes it ideal for an emergency set. The wet turbo and water-cooled exhaust manifold bring a level of safety and reliability found nowhere else in the marketplace. A true one of a kind yacht machine, Northern Lights is accepting orders for the M1066TMCA now. Contact your local Northern Lights factory representative for more information.
|
|
|
|
|
|
|
Reliability. Durability. Simplicity.
The M1066 Series marine generator sets are powered by new, US EPA Tier II compliant, Lugger diesel engines. Each generator incorporates new features that add high power density to the Northern Lights reputation for cast-iron reliability, durability, and simplicity.
An important decision.
Whether you are building a new yacht or repowering, your future enjoyment depends on the generator set you choose today. It will run day and night, so smooth, quiet operation, long engine life, and fuel consumption are major considerations. With so much depending on your new set, it pays to choose one that is built up to a high standard of quality; not down to a low price. It pays to choose Northern Lights.
The heritage continues.
Four decades of marine experience stands behind every Northern Lights. Yachtsmen like you have made them standard equipment on yachts from the world's premier builders. Service is handled by our international dealer network and our factory branches.
|
|
|
|
|
|
|
Reliability. Durability. Simplicity.
The M1276A2 series of Northern Lights generator sets are built to be run at high loads. Based on the solid reliability of a four-valve Lugger diesel engine, the M1276A2's can produce reliable on-board power, with a kilowatt range of 280 kW at 60 Hz (1800 RPM) or 230 kW at 50 Hz (1500 RPM).
It starts with engineering.
Northern Lights engineers its generators around some important core principles. At the forefront, is the commitment to creating power in a reliably efficient package. The cast iron exhaust manifold is combined with the expansion tank and heat exchanger housings on the M1276 series into a durable, robust jacket water cooling system.
If it’s not there, it can’t break.
Advanced engineering has minimized the number of hoses, belts and gaskets. Most service points are conveniently located on a common side. M1276A2’s are also designed to allow for longer time between oil changes than comparable models.
Electronics equal better fuel economy.
The ultra high pressure electronic fuel injection on the M1276A2 series allows for quick, smoke-less starts - even when cold - and improves fuel economy. The electronic control unit promotes protection by self-diagnosis.
Keep it safe, keep it running.
Safety and peace of mind come standard with your Northern Lights generator set as well. Northern Lights DC Logic System continually monitors vital engine functions. The automatic AC voltage regulator keeps voltage to +/- 1% to help protect the most sensitive instruments and electronics from power dips and surges. Automatic safety shutdowns for low oil pressure and high coolant temperature are standard features of the M1276A2 family.
|
|
|
|
|
|
|
The Northern Lights M944T is the new industry leader in power density in the 32-40kW range.
Producing a conservatively-rated 38kW at 60 Hz (1800 RPM), or 32kW at 50 Hz (1500 RPM), the M944T is based on a heavy-duty industrial block engine and custom marinized for optimal marine performance.
The cast iron, two-pass exhaust manifold promotes even temperature control and is formed of sturdy cast iron. The cupro-nickel heat exchanger is built with removable end caps for easy cleaning. The gear driven seawater pump is self-contained with no unreliable belts. The turbo charger is fresh water cooled for safety.
All systems on the M944T are designed to provide reliable power production in a small space. At 38kW, the M944T is smaller than some competitors’ 32. And because power is produced at a low 1800 RPM, engine wear is dramatically reduced.
Easily customizable, the M944T is an ideal set for increased power in the footprint of 25-33kW machine. Further maximizing engine room, is Northern Lights’ exclusive new base frame and sound enclosure configuration (see table on back). Add custom panels, mufflers or even a front PTO to power your winches, bow thrusters or deck gear. The M944T meets all current emission standards, providing clean and quiet power production.
All the reliability, durability and simplicity that has made Northern Lights the industry leader for five decades are on display in the M944T.
|
|
- Generator 200 kW
- More comfort on board
- Parallel operation
- Compact construction
- Long life
- Deutz 6-Cylinder V-Motor
|
|
|
|
|
|
|
A Mastervolt Whisper diesel generator serves as your very own on board power plant, one that is compact, economical, extremely quiet and easy to operate. This means that you can be certain of always having the required electric power at your disposal.
The Whisper 6, Mastervolt?s step up from the popular 3.5 version, can give you just that extra comfort you need. More capacity for simultaneously powering several devices comes within reach with this water-cooled two-cylinder diesel engine, permitting 2-plate cooking, the use of a medium-energy water maker, washing & drying etc. At the same time your batteries are being charged quickly, allowing you to switch back to silent inverter power for the remainder of the day. This is an ungrounded generator, suitable if you have an aluminium or steel vessel and wish to prevent electrolytic damage
Extensive monitoring and single-touch operating is easy because of the Digital Diesel Control (DDC) panel (even automatic start/stop on low battery capacity voltage and interval). Overall it is a model perfectly suited for smaller to medium boats fitted with a 230V electrical system. It is the power to be independent!
|
|
|
|
|
|
|
Are you often out sailing and have equipment on board that uses power continuously or has a high consumption level? If, at the same time, you also have space and weight capacity to spare, Mastervolt recommends the Whisper Ultra genset.
The Ultra models are designed for larger, more spacious sailing boats and motor yachts. They have a heavier three- or four-cylinder diesel engine that powers an alternator with two coils and four poles. This low speed means the Whisper Ultra is both very quiet and, due to reduced wear, requires even less maintenance compared to the high revolution models.
The 6 Ultra, the smallest generator of the Ultra series delivers nothing less than 5.7 kW and permits 2-plate cooking, the use of a medium-energy water maker, washing & drying etc. At the same time your batteries are being charged quickly, allowing you to switch back to silent inverter power for the remainder of the day. Extensive monitoring and single-touch operating is easy because of the Digital Diesel Control (DDC) panel (even automatic start/stop on low battery capacity voltage and interval). Overall it is a model perfectly suited for medium to large boats fitted with a 230V electrical system. It is the power to be independent!
|
|
- For continuous and intensive power consumption
- Power Take Off option available for on board hydraulic functions
- Specially treated metal sound guard
- Relatively small and lightweight
- Virtually vibration-free
- Most efficient initial surge tolerance
- Pure sine wave for continuous AC output
- Low-emission diesel technology
- Modern indirect-injection diesel engine
- Plug & Play installation
- Easy control and one-button operation
- Digital Diesel Control system included
- Easily removable sound guard with accessibility from all sides
- High class installation kits available
- Exhaust levels satisfy the most rigorous standards in both Europe and the United States (EPA compliant)
|
|
A Mastervolt Whisper diesel generator serves as your very own on board power plant, one that is compact, economical, extremely quiet and easy to operate. This means that you can be certain of always having the required electric power at your disposal.
The Whisper 6, Mastervolt's step up from the popular 3.5 version, can give you just that extra comfort you need. More capacity for simultaneously powering several devices comes within reach with this water-cooled two-cylinder diesel engine, permitting 2-plate cooking, the use of a medium-energy water maker, washing & drying etc. At the same time your batteries are being charged quickly, allowing you to switch back to silent inverter power for the remainder of the day.
|
|
|
BUKH DV ge-sets can be supplied with flexible or double-flexible mountings on a welded steel frame with marine or industrial generators, with two bearings or flanged-on with one bearing.
|
|
In designing the engines, consideration was given to their intensive use and to the desirability of easy and simple maintenance. These engines feature individual cylinder heads and wide inspection doors in the block, which makes access to the inside parts of the engine easy, and shortens the service time during maintenance and repair processes.
This series comprises six and eight cylinder in-line engines as well as twelve and sixteen cylinder 60º V-bank engines.
- Reliable
- Efficient
- Economic maintenance
- Environmental-friendly
|
|
In designing the engines, consideration was given to their intensive use and to the desirability of easy and simple maintenance. These engines feature individual cylinder heads and wide inspection doors in the block, which makes access to the inside parts of the engine easy, and shortens the service time during maintenance and repair processes.
This series comprises six and eight cylinder in-line engines as well as twelve and sixteen cylinder 60º V-bank engines.
- Reliable
- Efficient
- Economic maintenance
- Environmental-friendly
|
|
|
|
