Application
Engine room, refrigerated hold
Protection degree IP56
Hanging ring
|
|
Rugged and low profile luminaire
Tranbergs luminaires are all designed for use in rough environments.
It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. The design of Tranberg luminaires is based on many years of experience and extensiveresearch in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low
maintenance and a long trouble free life.
|
|
|
Tranbergs luminaires are all designed for use in rough environments. It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. The design of Tranberg luminaires is based on many years of experience and extensive research in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low maintenance and a long trouble free life.
|
|
Applications : emergency light, illuminated sign for passage ways, public areas, etc.
Approvals : according to the rules of relevant classification societies, additional VDE and IEC
Housing : zinc coated steel, powder coated white
Sign : PMMA, list of standard pictograms are available, other pictograms on customers requirements
Mounting : 4 mounting holes,Ø 4.5 mmcut out 243 x 60 mm
|
|
Polycarbonate sign.
Corrosion resistant aluzinc or stainless steel housing.
Epoxy powder coated finish.
Terminal block for incoming wiring.
Sign with 2” high red letters as per USCG requirements.
Single or double sided.
Recessed mounted.
8W fluorescent.
Custom signs available.
|
|
Autronica Fire and Security AS has an extensive range of emergency light systems and luminaires intended for small and plain systems to large and complex installations.
Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, weatherproof and vandal resistant applications and many other applications. Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, water proof and vandal resistant applications and many other applications
|
|
Emergency luminaires
Our specially designed ship emergency and exit luminaires provide a reliable and economical solution, without compromising on the style and compatibility of the products. We have advantaged our 30 years of expertise in the manufacture of highly demanding rolling stock and bus lighting solutions to meet the special requirements of shipboard applications.
|
|
Low location lighting
Based on the surface-emitting Optiline fibre optic lighting system, our LLL system allows for stylish and reliable Low Location Lighting. The basic system consists of an aluminium profile with fibre optic light modules mounted to it. High-efficiency and long-lasting LEDS are used as the light source. Installation of the Teknoware LLL system is easy, thanks to its modular construction and ready to fit, waterproof connectors. Aluminium profiles are available in both floor and wall-mountable models. The system is complemented by EXIT signs and end pieces.
The module operating voltage is a safe 6 V DC, and the system power consumption is a very low 20 mA/metre. A waterproof encased 230 V AC/6 V DC power source and battery backup unit are also available for the system.
|
|
|
|
|
|
|
KV LED - LIFERAFT LIGHT
Codice prodotto: EPLE0003
KV LED is one of the most powerful liferaft lights in toady%u2019s market. Its luminous intensity is 4.3 cd, which is greater than 2 mi (3.2 km), and is guaranteed for at least 12 hours. However VK LIGHT will continue to emit light for at least 24 hours in total. KV LED is different from any other lights because instead of bulbs it makes use of LED. The white high power LED used offers additional safety, increases the brightness and ensures its uniform distribution in all directions.
It is one of the most compact and light yet powerful external liferaft lights.
TECHNICAL SPECIFICATIONS
Approval Type - MED Directive96/98/EC as modified by MED Directive 2002/75/EC, Res. IMO MSC.81(70)
Material - UV stabilized composite polymer
Beam Angle - All directions of the upper hemisphere
Luminous Intensity - 4.3 cd, greater than 2 mi (3.2 km)
Activation - Pull activation
Lamp Type - White high power LED
Battery Type - Lithium %u2013 5-year replacement life (10-year storage life)
Operational Life 12 hours minimum at -30%u02DAC (-22%u02DAF) to +65%u02DAC ( 149%u02DAF)
Limited Warranty 1 year
* SIC Divisione Elettronica manufactures customized versions %u2013 OEM solutions - of internal and external liferaft lights as well.
|
|
Very bright SOLAS constant light, 2 h capacity, automatic activation after righting into floating position, stable waterproof and buoyant housing, droptested to 35 m, with holder.
Emergency lights mean playing an active role in your safety - they greatly improve your chances of being discovered in an emergency situation.
|
|
| ... products without information |
| |
- Allround signalling light in different colours for general warning purposes
- Seawater resistant
|
|
Main body of corrosion resistant (seawater) light alloy. Yellow polyurethane paint.
Globe of impact resistant polyamide available in colours red, blue, amber, clear or green.
Approved according to CENELEC EN50014, 50018.
|
|
Luminaire Emergency
Tranberg luminaires are all designed for use in rough environments. It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. the design of Tranberg luminaires is based on many years of experience and extensive research in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low maintenance and a long trouble free life.
|
|
| ... products without information |
| |
Applications : emergency light, illuminated sign for passage ways, public areas, etc.
Approvals : according to the rules of relevant classification societies, additional VDE and IEC
Housing : zinc coated steel, powder coated white
Sign : PMMA, list of standard pictograms are available, other pictograms on customers requirements
Mounting : 4 mounting holes,Ø 4.5 mmcut out 243 x 60 mm
|
|
Polycarbonate sign.
Corrosion resistant aluzinc or stainless steel housing.
Epoxy powder coated finish.
Terminal block for incoming wiring.
Sign with 2” high red letters as per USCG requirements.
Single or double sided.
Recessed mounted.
8W fluorescent.
Custom signs available.
|
|
Autronica Fire and Security AS has an extensive range of emergency light systems and luminaires intended for small and plain systems to large and complex installations.
Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, weatherproof and vandal resistant applications and many other applications. Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, water proof and vandal resistant applications and many other applications
|
|
Emergency luminaires
Our specially designed ship emergency and exit luminaires provide a reliable and economical solution, without compromising on the style and compatibility of the products. We have advantaged our 30 years of expertise in the manufacture of highly demanding rolling stock and bus lighting solutions to meet the special requirements of shipboard applications.
|
|
Low location lighting
Based on the surface-emitting Optiline fibre optic lighting system, our LLL system allows for stylish and reliable Low Location Lighting. The basic system consists of an aluminium profile with fibre optic light modules mounted to it. High-efficiency and long-lasting LEDS are used as the light source. Installation of the Teknoware LLL system is easy, thanks to its modular construction and ready to fit, waterproof connectors. Aluminium profiles are available in both floor and wall-mountable models. The system is complemented by EXIT signs and end pieces.
The module operating voltage is a safe 6 V DC, and the system power consumption is a very low 20 mA/metre. A waterproof encased 230 V AC/6 V DC power source and battery backup unit are also available for the system.
|
|
|
|
