TOTAL TIME REQUIRED
ECO 10 s
NORMAL 19 s
WATER CONSUMPTION
ECO 1,2 l
NORMAL 2,2 l
PUMPING HEIGHT
ECO 3 m
NORMAL 3 m
EMPTY 3 m
HORIZONTAL PUMPING DISTANCE
ECO 30 m
NORMAL 30 m
EMPTY 30 m
MINIMUM PRESSURE 1,7 bar
CURRENT CONSUMPTION
12 V (260 W) 20A
24 V (260 W) 10 A
ELECTRICITY CONSUMPTION
Elec 1,73.10-2 A.h (12 V)
1,02.10-2 A.h (24 V)
Elec 3,10.10-2 A.h (12 V)
2,02.10-2 A.h (24 V)
ELECTRONIC CONTROL
EMPTY
Operates continuously until the button EMPTY is released
|
|
TOTAL TIME REQUIRED
ECO 10 s
NORMAL 19 s
WATER CONSUMPTION
ECO 1,2 l
NORMAL 2,2 l
PUMPING HEIGHT
ECO 3 m
NORMAL 3 m
EMPTY 3 m
HORIZONTAL PUMPING DISTANCE
ECO 30 m
NORMAL 30 m
EMPTY 30 m
MINIMUM PRESSURE 1,7 bar
CURRENT CONSUMPTION
12 V (260 W) 20A
24 V (260 W) 10 A
ELECTRICITY CONSUMPTION
Elec 1,73.10-2 A.h (12 V)
1,02.10-2 A.h (24 V)
Elec 3,10.10-2 A.h (12 V)
2,02.10-2 A.h (24 V)
ELECTRONIC CONTROL
EMPTY
Operates continuously until the button EMPTY is released .
|
|
|
|
|
|
|
AquaT%u2122 Marine toilets
Available in a wide variety of different versions marketed under three basic models - standard and premium electric-powered or manual - the AquaT%u2122 marine toilet has been designed to meet virtually every conceivable lavatory installation situation onboard.
Priced competitively, the fine finish and well thought-through design of these toilets is remarkable. Made from white vitreous porcelain, and with corrosion resistant parts throughout, the AquaT%u2122 marine toilet, is quiet, robust and easy to clean.
Using the AquaT%u2122 marine toilet, water inlet and outlet takes place in two distinct steps. First the bowl is filled with clear water, and then the waste is flushed, leaving the bowl empty and clean, with no liquids sloshing about. Naturally, automatic back-flow prevention is incorporated into the design.
Most models can be ordered with standard, bevelled or low profiles in order to fit almost any hull and bulkhead configuration, and all are available in either compact or comfort versions so you can outfit your marine lavatory with the perfect-sized toilet, no matter what the layout.
Power models are shipped with well-proven Aqua Jet diaphragm pumps in either 12V or 24V versions, and the manual version incorporates an ergonomically designed, hand-powered piston pump that can be mounted for either left-hand or right-hand use.
It is probably fair to think of most toilets as commonplace products, but look at the features and you are sure to see that the AquaT%u2122 is far from ordinary. Quiet, hygienic and reliable, the AquaT%u2122 marine toilet is perfect for almost any marine toilet room.
|
|
|
|
|
|
|
AquaT%u2122 Marine toilets
Available in a wide variety of different versions marketed under three basic models - standard and premium electric-powered or manual - the AquaT%u2122 marine toilet has been designed to meet virtually every conceivable lavatory installation situation onboard.
Priced competitively, the fine finish and well thought-through design of these toilets is remarkable. Made from white vitreous porcelain, and with corrosion resistant parts throughout, the AquaT%u2122 marine toilet, is quiet, robust and easy to clean.
Using the AquaT%u2122 marine toilet, water inlet and outlet takes place in two distinct steps. First the bowl is filled with clear water, and then the waste is flushed, leaving the bowl empty and clean, with no liquids sloshing about. Naturally, automatic back-flow prevention is incorporated into the design.
Most models can be ordered with standard, bevelled or low profiles in order to fit almost any hull and bulkhead configuration, and all are available in either compact or comfort versions so you can outfit your marine lavatory with the perfect-sized toilet, no matter what the layout.
Power models are shipped with well-proven Aqua Jet diaphragm pumps in either 12V or 24V versions, and the manual version incorporates an ergonomically designed, hand-powered piston pump that can be mounted for either left-hand or right-hand use.
It is probably fair to think of most toilets as commonplace products, but look at the features and you are sure to see that the AquaT%u2122 is far from ordinary. Quiet, hygienic and reliable, the AquaT%u2122 marine toilet is perfect for almost any marine toilet room.
|
|
|
The Exalto Mariner toilets are nicely engineered and very cost effective. The toilets need to be connected to a pressurised water system for flushing. A solenoid valve to control the water supply is fitted as a standard. The Mariner toilets come complete with a control panel with an integrated flushing program. This control panel offers the choice to flush the toilet with eight (!) different water quantities. Very useful with a limited availability of flushing water or limited waste tank capacity. By simply pressing the related button, the toilet is flushed and the waste pumped out. You can also pump without flushing water. The toilet has a white porcelain bowl and a white seat and coated cover. The pump is made of ABS with stainless steel cutters, making the toilet suitable for both fresh and salt water. The pump has a reversible rotation, so any clogging is put right quickly and easily.
|
|
- Very quiet flush cycle - like a household toilet
- Single button flush actuator - with dual function water level control switch
- Can be plumbed to any pressurized water system that can provide a 3-1/2 GPM (13.5 LPM) flow rate
- Water control solenoid valve with anti-siphon breaker to prevent contamination of potable water supply
- White vitreous china bowl available in compact or comfortable household size
- Baked enamel seat & cover
- High capacity waste macerator and bowl discharge pump
|
|
- White Vitreous China Bowl Available in Two Sizes
- Baked Enamel Seat & Cover in Compact or Household Size
- Flexible Impeller Flush Pump
- Permanent Magnet Type Motor, Fully Enclosed, with Stainless Steel Shaft
- High Capacity Macerator and Bowl Scavenger Pump
- Built-in Back Flow Preventer
- All Corrosion Resistant Material for Marine Use
|
|
NEW 14" Deluxe Flush Toilet, part of the Deluxe Flush Range
Features:
- Space saving stylish design
- Regular household size seat
- Virtually silent operation for undisturbed sleep
- User selectable choice of "one touch" flush cycles for minimal water usage - a "Quick Flush" uses less than 1 quart (1 litre)
- Owner selectable choice of leaving bowl wet or dry after use
- Fresh or raw water rinse models
- Non-clogging large bore flush pump macerates waste
- Uses less than 1.0 amp/hour per day
- ISO 8846 MARINE - Ignition Protection
- Crevice free contours for added cleanliness and hygiene
- All plumbing and wiring easily concealed
- Angled or Vertical back vitreous china bowl
|
|
All VETUS toilets are equipped with an electric pump, which will macerate the contents and evacuate it in about 7 seconds. They are available in 12 or 24 Volt DC versions or alternatively, for 120 or 230 Volt AC (not model SMT02). VETUS toilets are both quick and quiet in operation (61dB(A)).
The main features of VETUS electric toilets are:
• A stylish and ergonomic porcelain bowl with an easy clean seat and lid of similar dimensions to a normal domestic toilet.
• The internal diameter of the outlet pipe is only 19 mm. This means that the toilet can be located in any convenient position aboard and can be connected simply to the waste water tank, using VETUS sanitation hose, type SAHOSE (see page 86).
• All 12 and 24 volt VETUS electric toilets have the following specifications:
- Models WCL, WCS and SMTO, have a combined pump/ macerator unit with a diameter of 96 mm. Model HATO has a separate pump and a 98 mm diameter macerator.
|
|
Marine Toilet - Electric Macerating Toilet for Ease of Use
The Newport represents state-of-the-art marine sanitation. Engineered for years of reliable, trouble-free service in virtually every application. Other features include:
-Compact design
-A single, convenient foot pedal controls all functions
-Saves water - uses approx. 1 pint of water per flush
-Fewer holding tank pump-outs
-Large clog-free discharge valve
-Beautiful china bowl; classic wood seat & cover
-Available with either side- or rear-mounted motor
Our marine permanent toilets are water-tested and designed to save space for boaters. From the Headmate manual-flush toilet to the electric-flush EasyFit, Thetford's Tecma line is a leader in marine sanitation.
|
|
|
Evolution (wall mounted with split system). In keeping with the new interior decoration trends, we have conceived a suspended WC with a sophisticated design and comfortable dimensions. This WC features a SPLIT system that permits to separate with the utmost ease the ceramic foot from the rest of the WC. This allows the entire assembly (the entire mechanical part) to remain attached to the bowl and, should the foot be removed, to be in full sight, facilitating as a result any servicing need and avoiding the recourse to a specialized technician. A unique system conceived to offer a technologically superior product.
|
|
The pump and all piping and valves are located within the base of the toilet. Under operation, the toilet utilizes its own pump to remove the waste and send it towards the sewage unit or holding tank. The toilet%u2019s operation is very quiet and does not require any additional macerator system because the solids are broken down with the toilet%u2019s own sheer pump. The toilet requires ½ gallon per flush and is able to pump the fluid 15%u2019 vertically and 150%u2019 horizontally. The toilet utilizes small bore discharge piping (1 ¼%u201D) reducing the typical piping space requirements as well as installation cost. Because the toilet has the ability to pump the fluid vertically, this allows the toilet to be installed below the sewage unit or holding tank inlet.
Available Models
The toilets are available in (3) different models to suit any marine application from crew boats, workboats, sport fisherman to mega yachts.
|
|
Macerator Pump
The TA3P10-19 macerator pump takes care of toilet waste. A rotary cutter shreds waste before it is pumped into or out from the holding tank. The pump should be connected as close as possible to the holding tank discharge outlet or the bowl discharge outlet. Note! Use unbleached lavatory paper only.
|
|
The sewage pump M is a self-priming diaphragm pump. It works without a macerator. Even bigger solids can be conveyed without damaging the pump because of the lip valves which have been installed. The self-locking valves make the pump non-reactive, i.e. it can be mounted to the side standing, hanging or sideways. The intake and discharge bent is revolving. This is necessary for better connecting possibilities of the suction and pressure hoses. The suction and pressure connections usually go from left to right. They can easily be changed, if the suction way should go from right to left or from the bottom to the top. All parts which come into contact with water can be ordered in red brass or aluminium. The pump can be delivered with a 12 V or 24 V motor.
Continuous operation 1 – 2 hours max.
Attention: The cross section of the pipe should never be less than 1 ½”/ 38 mm – or the pump capacity will not be achieved.
|
|
|
The Rheinstrom sewage pump FS 370 is a big, very hard wearing macerator pump which is suitable for continuous operation. It is not self-priming and therefore it must be installed either at the lowest part of the tank or lower than the tank itself. A macerator which chops up the conveying means is mounted in front of the pump. In case maintenance has to be carried out the pump’s body can easily be taken apart. In contrast to the sewage pump F the sewage pump FS 370 is suitable for continuous operation. Sewage tanks up to a size of 1 m³ are ideal for this pump.
|
|
|
|
|
|
|
WASTE EVACUATION
The Jabsco 18590 series DC macerator pump unit is the ideal solution for emptying marine holding tanks when not in a discharge restricted area. Self priming to 5ft this pump will empty a typical 30 gallon (115 Liter) holding tank in less than 3 minutes. Duty cycle of the pump is 15 minutes continuous which means a 180 gallon (680 liter) can be emptied in a single operation
It is recommended that holding tanks be flushed with several gallons of water after each pump out. This will reduce the possibility of a continued build up of sediment in the tank which could cause a potential blockage.
FISH BOX AND LIVEWELL TANK EVACUATION
The Jabsco Macerator Pump is the ideal pump for the emptying of Fish box and livewell receptacles. Very often the livewell tank will be above the waterline of the boat, when this is the case gravity can be used to empty the livewell tank. If not installed in this format then it is beneficial to use the Jabsco macerator pump for evacuation due to its self-priming capabilities and also it's grinding properties.
Fish boxes are typically mounted into the floor of the vessel and are very often below the waterline or only partially above the waterline. Again the Jabsco Macerator pump has the characteristics that lend themselves to this application. The bait residue particles of ice, fish scales and anything else that could potentially be found in the Fish-Box will be easily passed buy the Jabsco Macerator Pump, and the self priming capabilities are perfect for fish box installations common to many of today's sports fishing boats.
|
|
|
SHURflo’s Macerator pump is designed specifically for sanitation waste and fish box evacuations providing superior performance in harsh marine environments.
|
|
|
SHURflo’s Macerator pump is designed specifically for sanitation waste and fish box evacuations providing superior performance in harsh marine environments.
|
|
- Self-priming to a lift of six feet
- Flow rate to 6-1/2 gallons per minute
- Rated for continuous duty cycles of up to 1/2 hour ofuninterrupted pumping time (nearly 200 gallons ofsewerage transfer per cycle)
- Motor meets USCG regulation 183.410 and ISO 8846MARINE for ignition protection
- Motor is EMC compliant and CE marked
- Ports accept 1-1/2" hose with room for double bandclamps
- All pump components (non-flexible) are non-corrosiveplastic, stainless steel and bronze
- Diaphragm is made of Santoprene and the valves aremade of nitrile
- Pump housing is made of glass filled nylon
- The motor and gear drive are painted with a durableprotective coating
- A plastic motor splash guard adds additional protection
|
|
|
SANISPLIT is an automatic soil and waste water pumping unit, which collects the water from the kitchen and bathroom and pumps it into the collection tanks, even without the necessary gradient. SANISPLIT includes a powerful and silent centrifugal pump controlled by a pressure switch, which starts the pump as soon as the water arrives in the unit's collection tank.
|
|
Macerator Pump
The TA3P10-19 macerator pump takes care of toilet waste. A rotary cutter shreds waste before it is pumped into or out from the holding tank. The pump should be connected as close as possible to the holding tank discharge outlet or the bowl discharge outlet. Note! Use unbleached lavatory paper only.
|
|
The sewage pump M is a self-priming diaphragm pump. It works without a macerator. Even bigger solids can be conveyed without damaging the pump because of the lip valves which have been installed. The self-locking valves make the pump non-reactive, i.e. it can be mounted to the side standing, hanging or sideways. The intake and discharge bent is revolving. This is necessary for better connecting possibilities of the suction and pressure hoses. The suction and pressure connections usually go from left to right. They can easily be changed, if the suction way should go from right to left or from the bottom to the top. All parts which come into contact with water can be ordered in red brass or aluminium. The pump can be delivered with a 12 V or 24 V motor.
Continuous operation 1 – 2 hours max.
Attention: The cross section of the pipe should never be less than 1 ½”/ 38 mm – or the pump capacity will not be achieved.
|
|
|
The Rheinstrom sewage pump FS 370 is a big, very hard wearing macerator pump which is suitable for continuous operation. It is not self-priming and therefore it must be installed either at the lowest part of the tank or lower than the tank itself. A macerator which chops up the conveying means is mounted in front of the pump. In case maintenance has to be carried out the pump’s body can easily be taken apart. In contrast to the sewage pump F the sewage pump FS 370 is suitable for continuous operation. Sewage tanks up to a size of 1 m³ are ideal for this pump.
|
|
|
|
|
|
|
WASTE EVACUATION
The Jabsco 18590 series DC macerator pump unit is the ideal solution for emptying marine holding tanks when not in a discharge restricted area. Self priming to 5ft this pump will empty a typical 30 gallon (115 Liter) holding tank in less than 3 minutes. Duty cycle of the pump is 15 minutes continuous which means a 180 gallon (680 liter) can be emptied in a single operation
It is recommended that holding tanks be flushed with several gallons of water after each pump out. This will reduce the possibility of a continued build up of sediment in the tank which could cause a potential blockage.
FISH BOX AND LIVEWELL TANK EVACUATION
The Jabsco Macerator Pump is the ideal pump for the emptying of Fish box and livewell receptacles. Very often the livewell tank will be above the waterline of the boat, when this is the case gravity can be used to empty the livewell tank. If not installed in this format then it is beneficial to use the Jabsco macerator pump for evacuation due to its self-priming capabilities and also it's grinding properties.
Fish boxes are typically mounted into the floor of the vessel and are very often below the waterline or only partially above the waterline. Again the Jabsco Macerator pump has the characteristics that lend themselves to this application. The bait residue particles of ice, fish scales and anything else that could potentially be found in the Fish-Box will be easily passed buy the Jabsco Macerator Pump, and the self priming capabilities are perfect for fish box installations common to many of today's sports fishing boats.
|
|
|
SHURflo’s Macerator pump is designed specifically for sanitation waste and fish box evacuations providing superior performance in harsh marine environments.
|
|
|
SHURflo’s Macerator pump is designed specifically for sanitation waste and fish box evacuations providing superior performance in harsh marine environments.
|
|
- Self-priming to a lift of six feet
- Flow rate to 6-1/2 gallons per minute
- Rated for continuous duty cycles of up to 1/2 hour ofuninterrupted pumping time (nearly 200 gallons ofsewerage transfer per cycle)
- Motor meets USCG regulation 183.410 and ISO 8846MARINE for ignition protection
- Motor is EMC compliant and CE marked
- Ports accept 1-1/2" hose with room for double bandclamps
- All pump components (non-flexible) are non-corrosiveplastic, stainless steel and bronze
- Diaphragm is made of Santoprene and the valves aremade of nitrile
- Pump housing is made of glass filled nylon
- The motor and gear drive are painted with a durableprotective coating
- A plastic motor splash guard adds additional protection
|
|
|
SANISPLIT is an automatic soil and waste water pumping unit, which collects the water from the kitchen and bathroom and pumps it into the collection tanks, even without the necessary gradient. SANISPLIT includes a powerful and silent centrifugal pump controlled by a pressure switch, which starts the pump as soon as the water arrives in the unit's collection tank.
|
|
|
|
