The Answer to Automated Cutting
Eastman's low-ply CNC conveyor cutting system is suitable for continuous cutting of hundreds of materials including composites and industrial fabrics.
The Eastman conveyor cutting system automatically feeds and spreads material onto the conveyor and its internal blower system ensures material hold-down and cutting accuracy. The Eagle's™ gantry and tool head design utilizes a precision servo-controlled belt tracking system, with a rack and pinion drive, which can cut a wide variety of materials and thicknesses, with unprecedented speed and accuracy.
Eastman conveyor cutting systems are the CNC cutting system of choice at hundreds of wind, aerospace and industrial fabrics facilities around the world.
|
|
Eastman's Static Cutting Table provides superior cutting performance and increased throughput for cutting composite materials. Capable of marking, cutting, drilling and punching composite materials at speeds of up to 60 inches per second (152.4cm/s); the Eastman cutting system registers accuracy of +/- .015 inches (.4mm), with higher accuracies available.
The Eastman M9000 static cutting table that we purchased is being used to cut Kevlar® fabric. This fabric is cut and sewn into targets used for the ballistic testing in the development of Military body armor. The M9000 has reduced our labor costs and increased our uptime for this development work. This is critical in meeting the needs of the U.S. Military.
- Pat Fitzgerald, Dupont Company, Kevlar® Life Protection R&D
|
|
The Accu-Router I-MS machine is perfect for small to medium-sized solid wood parts, pre-dimensioned parts, and moldings. The table size for the I-M can either be 2'x 4', 3x 5', or 4'x 4'.
The I-MS features a regular vacuum table, but can also be enhanced with a Carter Flip Pod system. The Carter Flip Pod system is a vacuum piece-part work holding system. Machined locations in the "pod" panel are fitted with pods. When flipped, they allow vacuum to enter in a precise pattern to hold the part. Eliminates costly spoilboards in most applications and reduces set up time.
|
|
|
Because of the modular nature of our machines, and our extensive in-house CNC machining facilities, Aeronaut can manufacture special purpose machines based on existing components at very reasonable prices.
|
|
|
In the world of industrial and technical textiles, laser cutters are often the only choice for high production speeds on difficult materials.
|
|
|
The Elektron B2 combines the accuracy of the Elektron chassis with quick change bayonet mount tool holders. The Elektro B2 is the machine of choice for work such as corrugated box making where reciprocating blade cutters are required and for customers with existing Aeronaut bayonet tools.
|
|
|
The Elektron Mono WS and Elektron Mono LC computer controlled Plotter-Cutters from Aeronaut are rotary blade cutters designed to handle the widest fabrics and the toughest work-loads. The Elektron Mono WS and Elektron Mono LC are the most affordable of Aeronaut's range of plotter cutters they have been designed without compromise in terms of performance and long service life. All machines in the Elektron range share the same heavy duty chassis which has been designed to span 6.5 metres.
|
|
|
The Aeronaut Elektron Quattro is a brilliant industrial-strength plotter-cutter of amazing versatility. Designed to be future-proof, the Elektron Quattro has many unique features, carrying on from the tradition of other landmark Aeronaut machines. The Elektron Quattro can carry up to four steered tools. All machines are fitted with a marker and laser pointer holder.
|
|
|
Aeronaut Automation makes vacuum tables to suit our cutting systems. In fact we make some of the longest and widest vacuum tables around.
|
|
|
|
|
|
|
The Accu-Router Series III-C five axis machine is an excellent machine for cutting automotive plastics, aerospace advanced composites, and any parts which need an additional axis to create their special applications. Accu-Router employs the use of the Swiss precision spindle, IBAG. IBAG has a service facility in the U.S. for customer service.
The spindle is made expressly for 5 axis applications and features a tight included angle nose for easy manipulation of 3D parts. The unit is rated at 8HP continuous duty, programmable variable speed to 24,000 rpm, and comes standard in a power draw bar configuration using an ISO-30 precision tool holder. The IBAG premium spindle is available either as an automatic tool changer or as a manual quick-change system with push button release. The CNC control used on the five axis machine is the G.E. Fanuc 16i-MA model with Fanuc AC digital servo drive motors. Enclosures on the control are dust tight with gasketed doors. All connecting wires have 4 digit wire numbers relating to the schematic. Machines are custom designed to a customer's tolerance and applications.
|
|
The Accu-Router Series III-C is the ideal CNC router for high production panel processing. Accu-Router customers cut various materials such as: plywood, MDF, OSB, aluminum, composites, and plastics. The Series III-C is very popular for routing upholstered furniture frames, boat parts, airplane and helicopter parts-anything requiring panel processing.
The Fanuc control on the Series III-C includes options for rapid cornering, and faster cutting speeds. Additional memory may also be incorporated in the control.
|
|
Air cushion device to move the layers easily.
- Especially conceived to move the layers from the lying up zone to the cutting zone.
- Can be adapted on existing tables.
- Can be set on band knive machine , sewing machine for carpets.....
|
|
Robust frame, table top abrasion resistant.
- Conceived to receive laying up machines
- Square tubular frames 40 x40mm
- Jack of adjustment under each foot
- Table top in SODIPAN thickness 25mm
Options:
- Storage level
- Block drawer
- Also available: Movable table to move the laying up machine
|
|
TABLE WITH ADJUSTABLE HEIGHT
Height adjustable table top
from 0m720 till 1m00
Only on manual handle to rise the table top
useful weight on the table 100kg
standard sizes 700 x 2000 and 700 x 1600
For other dimensions, please contact SODIFA ESCA
|
|
Fabric cutting table for curtain's industry.
Size 2m X 3m on four wheels
Can be placed as you need folowing to your production
Table top in white color 19mm
Ribbons of measurement embedded on 2 sides for direct reading of dimensions.
Every others dimensions on request.
|
|
Semi automatic spreading machine
- Motorised and varispeed translation along the cutting table
- Adjustable feed
- Automtic edge contol device
- Automatic end cutter integrated
- Zig Zag spreading and fixe clamp in option
- Digital Counter
- Clear and easy pannel to operate
|
|
SEMI AUTOMATIC ECS MODEL
Semi automatic advance of the layer
Cut is automated
Equipped with a press guide on each side of the blade
Advance of the layer is preset and repetitive
Useful width 530, 810 or 1050mm
Useful height 60 or 90mm
|
|
Semi-automatic table for curtains and blinds
- Semi Automatic cutting tables for manufacturing ready made roller blinds, insect screens, curtains, samples, bed textile, etc.
- The cutting table guarantee an exact and square cut.
- Free craddle on one side.
- Cuttin tool can be placed quickly on every require position on the table top always in sqared position.
|
|
|
The Power Feed System simplifies material feeding by automatically adjusting tenstion for any material type. It feeds material onto the edge of the table while maintaining consistent tension. Comes in one-roll; two-roll; three-roll; six-roll with cart; or flat fold version.
|
|
The Heavy Carousel motorised storage
Available in many sizes and styles,
provides simple access to multiple material rolls
Useful width 1400mm till 4000mm
Capacity: 20, 40, 60 rolls
Maxi roll weight 500kg
With the press of a button, material rolls turn around the carousel, stopping on the desired roll.
|
|
