Hydronic centralized units HCU with no limit of capacity belong to Hydronic centralized systems (HCS). Systems above 60.000 btu/h are three-phase supplied. Centralized hydronics units sea water condensed circulate fresh water in a fan coils net for the distribution of heat and cold into the cabins.
Two models are available:
1) HCU single with off board only the electric box
2) PHCU preassembled of slightly bigger dimensions but including in a monobloc all fan coils net accessories such as the circulation pump, the expansion tank, the filling kit with manometer, the electric box, allowing so a cut of installation costs for boat yards. |
|
Sea water condensed chiller units properly designed for marine
applications
Suitable for installation in both new and used boats
4 models ranging from 16.000 up to 30.000 BTU/h
Ideal solution for 45 feet and more vessels
All the components are arranged on a 100% stainless steel
single chassis for long life service
All models available with reversing cycle for heat pump operation
High efficiency and quiet operation compressors
Highly corrosion resistant cupro/nickel sea water condenser
Thermostatic expansion valves
Deep condensate pan
Mechanical or digital remote controller
Each unit is gas pre-charged, leak checked and tested according
to accurate internal standards in the factory at the most critical
operation conditions
Environmentally friendly green gas R407C
Sea water, fan coil and air distribution circuit accessories available |
|
Cruisair R model remote condensing units are seawater-cooled, reverse-cycle air conditioners for cooling and heating in marine applications. The small R units are available in capacities from 5,000 to 16,000 BTU/hr (1.5kW to 4.7kW). Remote condensing units are installed in the engine room or other mechanical space and can operate with one or two Cruisair DX air handlers, of matched capacity, mounted up to 50ft (15m) away. Quality, marine-grade components are used throughout to ensure a long service life.
*Dependable recip. compressors are vibration isolated.
*Available with digital or mechanical controls.
*Optional vibration kit reduces noise transmission.
*Non-HCFC refrigerant available.
*Refrigerant: R22 or R-417A |
|
CS type remote condensing units are seawater-cooled, reverse-cycle heat pumps designed for cooling and heating marine environments. Standard CS condensing units are available in capacities from 6,000 to 16,000 BTU/Hr. To choose the proper size CS unit, primary consideration should be given to calculated BTU loads and available power supply. These condensing units can be installed with up to two Marine Air model E-FD air handlers. The total capacity of the E-FDs should be equal to the condensing unit capacity.
Model CS condensing units are designed for installation in the vessel’s engine room or other mechanical space. They are not affected by moisture, normal vibration, or ambient temperatures up to 140°F (60°C). No ventilation is required
*Hermetically sealed, high efficiency compressors provide a significant reduction in amp draw
*Copper encased cupronickel condenser coils are highly resistant to corrosion from continuous seawater flow
*Expansion device and check valve assemblies control load balancing during unit operation
*Pressure switches, thermal overloads, and start components afford constant system protection and proper operation
*Units charged with “Green Gas” R-417A (non HCFC) refrigerant are available |
|
| ... products without information |
| |
| ... products without information |
| |
Cruisair RE model DX air handlers are draw-through (ducted) units designed to be used with Type R remote condensing units. They are typically installed under a settee or bunk, or in a locker, with air ducted to a discharge grill high in the cabin. They are available in sizes from 4,000 to 36,000 BTU/hr (1.2kW to 10.5kW). Corrosion-resistant materials are used throughout, and the unit is fully insulated to prevent secondary condensation.
*Deep, “positive-flow” drain pan with anti-slosh, anti-fungal liner.
*Copper tube/aluminum fin evaporator coils are designed for hot/humid marine environment.
*Washable air filter included.
*Micro-particle filters available.
*Includes mounting kit with vibration isolators.
*Optional high-velocity blowers on REU models provide increased airflow and lower noise. |
|
E-FD remote evaporators are draw-through, ductable, DX air handlers incorporating variable-speed blowers and integral water-displacing condensate pans. Each unit is pre-charged, test run in all operating modes, and leak checked prior to shipping. E-FD units are ductable and designed to be installed in low cabin areas (under berths, lockers, etc.) and ducted to high supply air grilles.
These units have rotatable blowers providing flexibility to fit specific space requirements and allowing for proper duct work installations. Transition boxes may be used to supply air to more than one area from a single unit.
When choosing the proper model E-FD DX Air Handler, primary consideration should be given to calculated BTU loads and available power supply. A refrigerant line set is required to connect the E-FD to the Marine Air CS condensing unit.
*The unique compact modular design incorporates large plenum chambers for maximum efficiency
*Condensate drain pans are insulated to prevent sweating and have two ½” FPT drain connections
*Quiet, efficient, centrifugal blowers have fully insulated housings
*Large blower inlets provide maximum air flow across evaporator coils
*Charge Guard® protection provides sealed access ports, ensuring environmental protection and system integrity |
|
|
|
