As an indication, a traditional bulb of 10-15 W replaces
16 led under plastic sphere
Lighting = WHITE 360°
Consumption = 1,8 W
Illumination = 32 lumens
Tension = 24 V cd.
Detailed description:
Total height bulb = 53 mm
Diameter bulb = 24,5 mm
Diameter base = 15 mm
Height base = 20 mm
Contacts = 2
Pins = shifted
Reference: 04BAY15D16-24
|
|
Recessed downlight, emitting direct and diffused light, suitable for any environment. Stainless steel AISI 316 trim ring available in either polished or matt nickel finishings.
FOR INTERIORS
ADJUSTABLE
INDEPENDENT OPTICS
SANDED GLASS
|
|
Wall light, emitting direct and diffused light, suitable for any environment.
Brass body available in either polished or matt nickel or 24k gold finishings.
FOR INTERIORS
ADJUSTABLE AND EXTENSIBLE
|
|
Appliques
with switch
Socket: B15d
Operating voltage: 12/24 V
Max power: 20 W
Socket: B14
Operating voltage: 110/220 V
Max power: 25 W
Finish: polished chrome o satin
Lampshade colors: Linen, sand, brown, bordeaux red
Max dimensions: 173X189 mm
|
|
|
195mm long recessed vertically adjustable 90 degrees downlight to 30 degrees wall/picture light with solid machined brass bezel finished in Bright Chrome plate with black anodised aluminium lamp holder and black powder coated steel back body.
|
|
We are often asked to make one off exclusive fittings, sometimes to compliment our main lighting range and sometimes to make individual items that have functions else where.
For example we were asked to design a Winch Switch and incorporate LED lighting. We machined the body in 316L Stainless Steel and used 2x1w blue LEDs set into an acrylic backing.
The effect was stunning.
|
|
To date we have supplied a few projects with our Wall Light fixtures. Supplied with or without shades, the lathe turned brass fittings can be made to match the downlights.
For example if you have the Mayfair model as your downlight, we can incorporate twisted braid into the stems, colour co-ordinate them and the mounting plate will be a Mayfair trim.
|
|
Recessed halogen light with frosted lens.
Colours Available:
White, Plated Gold, Chrome , Matt Silver or Silver Sand
|
|
| ... products without information |
| |
- Divide your consumption by 10 !
- Very high efficiency LED lamp
- Very long life: >50,000h (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Power consumption: 1W typ.
- Current draw: <90mA @ 12VDC / <45mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 300° horizontal / 120° vertical
- Dimensions: Ø 0.79"
- Available in lengths: 1.42" / 1.5" / 1.62"
- Pictures and information may be changed or updated without notice
|
|
- Divide your consumption by 20 !
- Very high efficiency LED lamp
- Very long life: >50,000h @ 25°C (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Very low power consumption: 1.8W typ.
- Current draw: <150mA @ 12VDC / <80mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 360° horizontal / 120° vertical
- Dimensions: Ø 1" x 2.3"
- Available with BA-15S or BA-15D or BAY-15D bayonet base
|
|
|
|
