WAECO PerfectCharge – IU0U automatic chargers in premium quality
A new, trend-setting model generation that combines stateof-the-art charging technology with excellent user comfort. Winner of the coveted “Caravaning Design Award 2008/2009“. Well-designed detail solution: the display is integrated in the unit at a 45° angle so that it can easily be checked from various positions.
Multi-stage IU0U charging characteristics ensure fast and gentle charging of all types of batteries. As double and triple chargers, the premium appliances can be used for simultaneous charging of several batteries. Supplied with IEC plugs to fit sockets across the whole of Europe. Features for easy installation: individually adjustable clip-on mounts, cable organiser, mounting plate. Overcharge protection, adjustable charging capacity, battery conditioning/refreshing function, sleep mode.
Available in various capacity ratings, for 12- and 24-volt batteries. Remote control and temperature sensor as optional accessories.
|
|
SBC ADV PLUS Mini/Low Power
Models: 100/140/250/285 and 100DR/140DR/250DR/285DR
Advantages:
• Three stage IUoU battery charging.
• Multiple outputs in order to charge more groups of batteries (internal battery isolator diodes).
• Charge selector for liquid/gel electrolyte batteries.
• Low residual fluctuation on output (ripple lower than 30 mV RMS).
• Universal AC supply input (DR models).
• Compatible with every kind of generator.
• Capable of operating in a wide range of ambient temperatures.
Protections:
• Reverse polarity (with internal fuse)
• Overload
• Output short circuit
• Overheating
Safety classification EN 60335-2-29
EMC Class EN 55022/B
|
|
|
|
|
|
|
SBC ADV PLUS Medium Power
Models: 300FR/500FR/700FR/650FR
Advantages:
• Three stage IUoU battery charging.
• Multiple outputs in order to charge more groups of batteries (internal battery isolator diodes).
• Differentiated charging for liquid electrolite or gel batteries.
• Integrated fuses inside the battery chargers (one for each output).
• Thermal battery protection (with optional sensors).
• Ability of providing full output power with low supply voltage.
• The possibility of using the battery charger as a power supply without batteries.
• Low residual fluctuation on output (ripple lower than 30 mV RMS).
• Universal AC supply input (FR models - SBC 1450 ADV and SBC 1950 ADV escluded).
• Compatible with every kind of generator.
• Capable of operating in a wide range of ambient temperatures.
• Variable speed for the cooling fan.
• High-technology control panel.
• Automatic and manual half power mode (with optional RCM 1620).
• CAN BUS interface for data transfer.
• Current sharing (only HI-Power)
Protections:
• Reverse polarity (with internal fuses)
• Overload
• Output short circuit
• Overvoltage in output
• Overheating
• Battery overtemperature (with optional sensors)
Safety classification EN 60335-2-29
EMC Class EN 55022/B - EN 5022/A
|
|
|
|
|
|
|
SBC ADV PLUS HI Power
Models: 1100FR/1450/1950
Advantages:
• Three stage IUoU battery charging.
• Multiple outputs in order to charge more groups of batteries (internal battery isolator diodes).
• Differentiated charging for liquid electrolite or gel batteries.
• Integrated fuses inside the battery chargers (one for each output).
• Thermal battery protection (with optional sensors).
• Ability of providing full output power with low supply voltage.
• The possibility of using the battery charger as a power supply without batteries.
• Low residual fluctuation on output (ripple lower than 30 mV RMS).
• Universal AC supply input (FR models - SBC 1450 ADV and SBC 1950 ADV escluded).
• Compatible with every kind of generator.
• Capable of operating in a wide range of ambient temperatures.
• Variable speed for the cooling fan.
• High-technology control panel.
• Automatic and manual half power mode (with optional RCM 1620).
• CAN BUS interface for data transfer.
• Current sharing (only HI-Power)
Protections:
• Reverse polarity (with internal fuses)
• Overload
• Output short circuit
• Overvoltage in output
• Overheating
• Battery overtemperature (with optional sensors)
Safety classification EN 60335-2-29
EMC Class EN 55022/B - EN 5022/A
|
|
Intelligent Battery Chargers
The IC Series Intelligent Battery chargers offer an ideal way of charging any type of lead acid battery safely and reliably.
The rugged fully protected unit (IP67) can be used in a variety of applications including on trucks, off road vehicles, fire vehicles, boats, caravans and in depots and workshops.
|
|
The IC Series Intelligent Battery Chargers offer an ideal way of charging any type of lead acid battery safely and reliably. The rugged, fully protected unit (IP65) can be used in a variety of applications including on trucks, off road vehicles, boats, caravans and in depots and workshops.
The Alfatronix IC Series is suitable for all types of lead acid batteries. Charging is through a 3 stage system. The first stage is the bulk charging phase. This state is indicated when the yellow LED is illuminated and continues through to stage 2 of the process. When the current is below 10% of the maximum output, the charger automatically adjusts to reduce the output voltage to reliably top up the battery. At this stage the green LED is illuminated indicating that the battery is fully charged. Should the voltage level fall below the nominal values during the maintenance stage, the charger will go back to step one and repeat the process.
|
|
BC 12V 60A
Codice prodotto: EPC80002 - EPCA0002 (TRIPLE OUTPUT)
The 12Vdc 60A BATTERY CHARGER:
- is suitable for recharging 12Vdc LEAD BATTERIES either with liquid electrolyte or GEL.
- can be used as fixed or mobile equipment.
- can recharge batteries having capacity up to 900Ah.
This battery charger complies with the Council Directives 73/23/EEC, 89/336/EEC and 93/68/EEC concerning the CE labelling of electric and electronic equipment.
|
|
BC 12V 5A BATTERY CHARGER 5A
Codice prodotto: EPCI0001
The 12Vdc 5A BATTERY CHARGER:
- is suitable for recharging 12Vdc LEAD BATTERIES, either with LIQUID electrolyte or GEL.
- can be used as fixed or mobile equipment.
- can recharge batteries having capacity up to 75Ah.
This battery charger complies with the Council Directives 73/23/EEC; 89/336/EEC and 93/68/EEC concerning the CE labelling of electric and electronic equipment
|
|
Install Mastervolt Mass battery chargers and rest assured that your batteries are always quickly and completely charged, whether you are at home, on the road or at sea with low shore power or limited supply.
Designed for larger, more professional systems with larger battery capacities, the basic technology consists of high-frequency electronics with no heavy or noisy transformers. Thanks to the intelligent cooling concept, the Mass battery charger offers maximum performance, even in the hottest engine room. Besides the fast and complete charging of two batteries up to 150 Ah (12V) (recommended) this charger also functions as a supply unit when the input is low, automatically making up the full capacity in the 12V circuit. Mastervolt’s three-step charging method guarantees optimum efficiency, meaning your batteries will perform better and last much longer. Its direct current outlet is so clean that the battery charger itself can be used as direct power source, even without a battery.
|
|
The new Centaur range of battery chargers from Victron Energy have been designed to be a true world-wide product. Universal compliance and input/output specifications are cornerstone characteristics of the new range from the established Dutch manufacturer.
Designed to meet the requirements of both CE for Europe and UL for the United States, the Centaur model range features auto-ranging input covering 90-265Vac 50/60Hz input meaning they can be used anywhere in the world. Crucially, and unlike other products that state universal input, the Centaur range will maintain full output power within the entire specified range.
|
|
Xantrex TRUECHARGE RV
Quick battery charging and safer DC power distribution for RVs. XantrexTM TRUECHARGETM RV is the perfect DC power source for the most demanding RVs.
|
|
- Duracell® 2 AMP Battery Maintainer
- Duracell® Battery Charger - 15 AMP
- Duracell® Battery Chargers - 6 AMP, 12 AMP & 25 AMP
- Duracell® Emergency Car Starter
- Duracell® Instant Jumpstart System
- Truecharge 10 & 10TB - 90-135 VAC, 50/60 Hz
- TRUECHARGE2 Battery Chargers
- XC Battery Chargers - 12V & 24V
- XPower Battery Chargers - 120 VAC/50-60 Hz
|
|
All features of a sine wave inverter and charger in one compact enclosure.
UPS functionality: seamless transfer from external AC to inverter supply.
A unique AC power management system will prevent overload of a limited AC source. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery: where peak power is often required only for a limited period, the Phoenix MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery.
|
|
