Consilium's experience in designing and manufacturing Marine Radar Systems goes back to the last 30 years and is distinguished by innovative radar solutions.
Consilium is extremely proud to introduce a new series of improved X-band radars which provide mariners with even better detection capability. The new configuration is characterized by reduced weight, small dimensions and compact electronics thereby offering the proper solution for installation even on small High Speed Crafts.
ARPA Radar Display
The Selux ARPA display is produced in three different configurations.
The deck configuration provides an optional display deck stand which can also house the electronic cabinet. The modular configuration with monitor, keyboard and ARPA electronic cabinet supplied as three separate modules which can be flush mounted into the bridge console to the customers´ preference.
The table top configuration where the monitor and key- board are housed into an ergonomic console while the ARPA electronics are contained in a separate bulkhead mounted cabinet.
|
|
|
The RADARPILOT 1100 - Represents a milestone in technical performance, ease of operation, simple maintenance and future oriented system technology
|
|
User friendly, clear and logically structured interface
Handles primary radar information
Acquires and processes ARPA tasks (up to 256 targets)
Displays AIS target on the radar display and targets parameters output on the information panel
Official ENC/S-57 and Transas TX-97 format electronic vector charts overlay features assist safe and convenient navigation
Displays routes loaded from external systems' ECDIS/positioning system
Associates AIS targets with ARPA targets
Can connect up to 2 GPS, 2 GYRO and 2 LOG+1 DLOG
Configuration of 2 Radar stations with SW scanner interswitch and provides ability to change rights of navigational Master (station with rights for navdata sources)
Displays information from 2 targets for data comparison
Fine adjustment of brilliance and contrast for perfect radar picture tuning
Flexible in both configuration and chart functionality
|
|
|
CHARTRADAR 1100 - The versatile radar system including state-of-the-art ENC presentation.
|
|
|
|
|
|
|
The marine ARPA/RADAR system employing a 23.1-inch color LCD, developed with the state-of-the-art technologies and JRC's cultivate experience
INTRODUCTION
JRC JMA-9900 series ARPA/Radar is developed to enhance the radar performance, user-friendly operation and visibility, which meet the performance standards of radar, ARPA and AIS information indication, which are specified in IMO. The JMA- 9900 main functions include; sea and rain/snow clutter suppression, sensitivity adjustment, interference reflector, bearing and range measurement using a trackball, fixed/variable range markers and electronic bearing line, ARPA, and AIS information function. In addition, this has the functions of color display setting, own track display, NAV line and mark display, True Motion presentation, radar performance monitoring and built-in switchover function (Inter-switch) up to 2 radars.
The software-based signal processing of JMA-9900 series radar will provide a superior visibility with automatic control of gain, tune, anti-sea-clutter and anti-rain-clutter, which are adjusted for suitable radar condition. Furthermore the enhanced echo-image processing will provide stable target-tracking condition with reducing target loss and transfer to close-by another target.
FEATURES
Tilt-type display bringing superior visibility and effective shading of sunlight
23.1-inch color LCD providing easy interpretation with clear vision
Trackball available for pointing and clicking operation
Dedicated and user keys contributing stress-free operation
Suppression of sea and rain-clutter adjusted automatically
Stable ARPA target-tracking on superior signal processing
|
|
FURUNO ARPA Radar FAR-28x7 series and FAR-21x7 series fully meet the latest performance standards of IMO and IEC for all ships and for ships under 10,000 GT, respectively. It is designed to meet the demands of today's maritime industry.
The FAR-21x7/28x7 series radar has DVI (Digital Video Interface) facility integrated to deliver crisp and clear radar images. Target detection is enhanced by sophisticated signal processing techniques featuring superb short range detection. AIS information scheme can be incorporated when AIS transponder/receiver is interfaced, thereby further enhancing situation awareness of the operators. FURUNO ARPA Radar FAR-21x7/28x7 series brings greater bridge performance and enhanced navigation accuracy, increasing both operating efficiency and safety level at sea.
|
|
|
JRC JMA-9900 series ARPA/Radar is developed to enhance the radar performance, user-friendly operation and visibility, which meet the performance standards of radar, ARPA and AIS information indication, which are specified in IMO. The JMA- 9900 main functions include; sea and rain/snow clutter suppression, sensitivity adjustment, interference reflector, bearing and range measurement using a trackball, fixed/variable range markers and electronic bearing line, ARPA, and AIS information function. In addition, this has the functions of color display setting, own track display, NAV line and mark display, True Motion presentation, radar performance monitoring and built-in switchover function (Inter-switch) up to 2 radars.
|
|
|
The Kelvin Hughes NTD ARPA is a rugged, compact and flexible naval radar display system for use both on the bridge and in the ops room (CIC) of warships. The NTD ARPA satisfied IMO ARPA requirements for navigation Radar. Configurations can be provided for all types of ship and submarine in both new-build and retrofit projects. The system is able to interface to and control a wide range of radar transceivers and antennae.
|
|
|
|
|
|
|
K-Bridge ARPA radar is our latest series of type approved ARPA radars. It is provided as a stand alone ARPA radar or as a fully integrated part of the K-Bridge integrated navigation system. It provides superior target tracking and has advanced navigation integration with multi-sensor input. K-Bridge can include electronic chart functions and automatic navigation and track steering when part of a K-Bridge integrated bridge system. The colour display presents a square radar picture, which gives an increased active radar display area for better traffic surveillance. A dedicated operator panel gives ease of operation
Radar functions
- Range scales: 11 (0.125 - 96nm)
- Manual and automatic clutter reduction: Yes
- Echo stretch: Yes
- Stern indicator: Yes
- Bearing scale: Always gives the correct bearing from own ship
- Electronic Bearing Lines (EBL): 2
- Curved Electronic Bearing Lines (EBL): Yes
- Variable Range Makers (VRM): 2
- Parallel index lines: Yes
- Square radar picture: Yes - 27% larger radar area covered
- Colour palettes: Five, to match different light conditions
- Integrated handling of navigation sensors: Available
- Chart underlay available: Yes
|
|
- Compliance with IMO performance standards
The X / S-band, 2-unit / 3-unit, 25 / 30kW conforms to IMO performance standards.
- 23.1-inch color TFT display with high resolution.
- Enhanced Performance and Functionality
- Effective monitoring to prevent collision and grounding
- System construction featuring easy operation
- ARPA function: auto-acquisition and tracking up to 50 targets
- High sensitivity scanner
- Full Inter-switch Function (Option)
- Self-diagnostic / program capacity
- Bridge system accommodation
|
|
|
Our NSC radar systems provide excellent performance and high reliability under all conditions. A clearly structured user interface provides all important information at a glance, allowing the user to concentrate on navigational tasks. The system ensures easy integration of AIS, ECDIS / GPS, heading information, autopilot remote control panel, SENC-Data, conning and alarm contacts. Integrated interswitch offers easy access to all radar information. In addition to NSC radar, NSC chartradar presents ECDIS information for increased efficiency during watch keeping.
|
|
- Route planning and route monitoring facilities
- Wide variety of warning facilities contribute to safer and more efficient navigation
- Grounding warnings, safe depth contours
- Chart database loaded and updated using CD-ROMs
- Sharing of route with ECDIS
- Meets DNV NAUT-AW Requirements
- Utilizes advanced signal processing technique to achieve outstanding detection in rough sea
- Terget data from ARPA radar and AIS transponder to aid collision avoidance
- Up to 100 ARPA targets can be tracked and displayed
- Up to 200 AIS targets can be displayed
- High-resolution LCD shows clear radar images
- Compatible with IHO S-57 Edition 3.0/3.1
- Integration into total navigation network INS VOYAGER
|
|
|
The next generation multi-function military Radar system designed to meet the 2008 IMO performance regulations providing enhanced radar processing and tracking performance. NTD Digital is driven by Kelvin Hughes' latest common-core processor system. The system can be a stand alone Radar or can provide multi-function capability when integrated into a bridge system. In either case NTD Digital delivers exceptional performance together with minimal through life costs.
|
|
