There%u2019s no question that the use of articulated pipe systems for marine loading and marine unloading bulk liquid cargo from barges and small ships is the better way to complete the task.
%u2022 Faster and more economical: one person can do the work of two or more in a fraction of the time and, in turn, for a fraction of the cost
%u2022 Safer: the potential for injury and all its costs is reduced to its lowest when partial or full automation replaces brute strength
%u2022 More environmentally responsible: no more risk of burst hoses or leaks and spills caused when hoses %u201Cget away%u201D from their handlers
No wonder so many companies have adopted marine loading arms, often more than 20 years ago%u2014and why many more are realizing these advantages every day. It%u2019s also no wonder there is increasing pressure by port authorities and other government agencies to adopt the faster, safer, cleaner alternative to wrestling with flexible hoses%u2014Carbis marine loading arms addresses these issues!
Recently, however, the only sources for marine loading arms have been offshore manufacturers. And, in light of recent events, their ability to overcome unfavorable exchange rates, huge distances, and other challenges, have left the market hungry for a domestic source.
Today, Carbis is that U.S. source%u2014for marine loading arms that feature superior design and quality construction, as well as the rapid and dependable service and support that domestic shippers have been missing.
|
|
River Barge Loading Arms
FBMA - Fully Balanced Marine Arm
Highly simplified design marine loading arm for use to offload barges or small tankers where a limited operating envelope is required.
|
|
Carbis marine loading arms for barge and small ship applications are typically custom designed and we offer the in-house capabilities to get you the right solution quickly. Our design staff includes more than 30 mechanical, structural, and industrial engineers and support staff to guide you through concept, design and material specification to achieve the right solution for your specific needs.
Our marine loading arms are based on a proven articulated piping system with three split flange swivel joints that allow a full range of motion for connections and compensation for vessel movement. Marine Arms are available in 4" to 12" piping sizes, these units can be customized in many ways to meet your specific needs for end connections, reach, and range of motion. Designs can include manual counterweights or full hydraulic operation. See the table on the right for nominal flow rates for various piping sizes.
|
|
DCMA - Double Counterweighted Marine Arm
Two counterweight assemblies balance independently the inboard and outboard sections of the arm, requiring less space for counterweight clearance behind the arm and avoiding any interference with jetty piping/ equipment even when the arm is moved out of its normal separating range.
|
|
LA-DCL PORT LOADING ARMS
LA-DCL Port Loading Arms is connecting Link structure type.It is fully balanced in all position.Arms is lighter and can be used in new and old jetty.
LA-DCL Port Loading Arms is designed to be both maual and hydraulic type.
Size:6" 8" 10" 12" 16"
Standard design incorporates:
All steel construction
Low torque swivel joints provide easy handing
Mechanical parking locks
Handing lines(only for manual type)
Two separate balance system
High flow rates at low pressure drop
Seal Material:--Nitrile
--Viton
--PTFE
Auxiliary Accessories:
Alarm system
Insulating flange
Manual Vacuum breaker
Automatic Vacuum breaker
|
|
LA-F PORT LOADING ARMS
LA-F Port Loading Arms is all steel construction and is the simplest type loading arms.It fully balanced in all psition.Swivel joints can be replaced without any lifting equipments.
LA-F Port Loading Arms is designed to be manual type.
Size:6" 8" 10"
Standard design incorporates:
All steel construction
Low torque swivel joints provide easy handing
Mechanical parking locks
Handling lines
Two separate balance system
High flow rates at low pressure drop
Seal Material:--Nitrile
--Viton
--PTFE
|
|
RCMA - Rotary Counterweighted Marine Arm
A single main counterweight assembly is used to balance the inboard and outboard sections of the arm, with an additional small countermight assembly to adjust inboard arm balancing.
|
|
LA-C PORT LOADING ARMS
LA-C Port Loading Arms is sheave structure type,Primary and secondary counterweight consist rotary balanced system make Arms easliy balance.
LA-C Port Loading Arms is designed to be both maual and hydraulic type.
Size:8" 10" 12" 16"
Standard design incorporates:
All steel construction
Low torque swivel joints provide easy handing
Mechanical parking locks
Handing lines(only for manual type)
Rotary balance system
High flow rates at low pressure drop
Seal Material:--Nitrile
--Viton
--PTFE
--Special
Auxiliary Accessories:
Alarm system
Insulating flange
Manual Vacuum breaker
Automatic Vacuum breaker
|
|
|
|
|
|
|
There%u2019s no question that the use of articulated pipe systems for marine loading and marine unloading bulk liquid cargo from barges and small ships is the better way to complete the task.
%u2022 Faster and more economical: one person can do the work of two or more in a fraction of the time and, in turn, for a fraction of the cost
%u2022 Safer: the potential for injury and all its costs is reduced to its lowest when partial or full automation replaces brute strength
%u2022 More environmentally responsible: no more risk of burst hoses or leaks and spills caused when hoses %u201Cget away%u201D from their handlers
No wonder so many companies have adopted marine loading arms, often more than 20 years ago%u2014and why many more are realizing these advantages every day. It%u2019s also no wonder there is increasing pressure by port authorities and other government agencies to adopt the faster, safer, cleaner alternative to wrestling with flexible hoses%u2014Carbis marine loading arms addresses these issues!
Recently, however, the only sources for marine loading arms have been offshore manufacturers. And, in light of recent events, their ability to overcome unfavorable exchange rates, huge distances, and other challenges, have left the market hungry for a domestic source.
|
|
For the transfer of LNG, refrigerated, high density or high specific gravity products, these arms are also available in a different configuration - the "S" or supported version - where the fluid line is separate from the mechanical structure:
- RCMA - S
- DCMA - S
|
|
LA-CS PORT LOADING ARMS
LA-CS Port Loading Arms is separate support structure.The pipe and swivel joints are totally separate from the support structure and all external loads are taken directly by the support structure.
LA-CS Port Loading Arms is designed to be both hydraulic and manual type
Size:6" 8" 10" 12" 16"
Standard design incorporates:
Both support structure and product line are steel construction
Low torque swivel joints provide easy handing
Mechanical parking locks
Hangding Lines(only for manual type)
Counterweight balance sestem
High flow rates at low pressure drop
Suit to oil chemical and low temperature medium
Seal Material:--PTFE
--Special
Auxiliary Accessories:
Vapour recovery line
Alarm system
Insulating flange
Adjustable support jack
Emergency Release System
Manual Vacuum breaker
Automatic Vacuum breaker
|
|
DCMA-S - Double Counterweighted Marine Arm "S"
This arm is fully balanced in all positions. Two independent counterweight systems are used to balance the inboard and outboard sections of the arm. The "S" or supported version is designed to separate the product carrying line from the mechanical structure.The DCMA design requires less space for counterweight clearance behind the arm.
|
|
RCMA-S - Rotary Counterweighted Marine Arm "S"
This arm maintains the product carrying line separate from the mechanical structure with only a single counterweight system used to balance the inboard and outboard sections of the arm.
|
|
|
Standard systems and jumper assemblies can also be supplied mounted on road or rail trailers to accelerate loading and efficiency at terminals with limited dock space or where dock space is more frequently used for non liquid cargo.
|
|
|
Woodfield Marine Loading Arms are generally designed in accordance with the O.C.I.M.F. %u2018design and construction for marine loading arms%u2019 and offer advantages in enhanced safety and reliability in operation. Woodfield Marine Loading Arms need a minimum of service attention and only require routine maintenance.
|
|
|
|
|
|
|
MLA 260
The MLA260 series is the most efficient range of marine loading arms on the market, due to the slim design and the availability of a number of design options to ensure that specific site requirements are met in the best possible way.
The MLA260 can be used with virtually all liquids and gases that are capable of being transferred through pipes. The use of a unique double inboard arm has resulted in the smallest design footprint possible whilst ensuring that the loads encountered at the MLA260 base plate are the lowest when compared with any other type of arm.
The MLA260 model can be configured with more than one fully separated, self-supporting product lines, which are designed to absorb all possible forces associated with structural mass, fluid weight, pressure load and wind load.
Full balance of the loading arm is provided by means of a rigid pantograph link, which connects the outboard arm to the rotating counterweight. Special care has been given to the rotating pivots of the pantograph bar both in design and in material selection thus assuring smooth operation with minimum maintenance. Four different executions are available
|
|
MLA 262
The MLA262 series consists of a frame type construction including separate supporting structure with floating product and/or vapour pipe. Full balance of the loading arm is provided by means of a %u201CCable wheel link%u201D rotating counterweight-balancing system.
The MLA262 series is specifically used for cryogenic or highly corrosive or toxic chemical service.
|
|
|
|
|
|
|
MLA 260
The MLA260 series is the most efficient range of marine loading arms on the market, due to the slim design and the availability of a number of design options to ensure that specific site requirements are met in the best possible way.
The MLA260 can be used with virtually all liquids and gases that are capable of being transferred through pipes. The use of a unique double inboard arm has resulted in the smallest design footprint possible whilst ensuring that the loads encountered at the MLA260 base plate are the lowest when compared with any other type of arm.
The MLA260 model can be configured with more than one fully separated, self-supporting product lines, which are designed to absorb all possible forces associated with structural mass, fluid weight, pressure load and wind load.
Full balance of the loading arm is provided by means of a rigid pantograph link, which connects the outboard arm to the rotating counterweight. Special care has been given to the rotating pivots of the pantograph bar both in design and in material selection thus assuring smooth operation with minimum maintenance. Four different executions are available
|
|
|
|
|
|
|
Woodfield Systems Limited%u2019s managing director, Richard Williams, says this co-operation heralds a new era of cost effective solutions for the loading arm market place: %u201CWe are very happy with our world-wide partners and the quality of their work. We have worked very hard and invested heavily in communication and experience transfer with our nominated construction houses, and as a result our design engineers have found working with the constructors to be easy and efficient.%u201D
Temperatures from -1640C to +2000C
The Woodfield range of Marine Loading Arms extend from 4%u201D dia. up to 24%u201D dia., for handling crude oil, refined products, slurries, chemicals, LPG, LNG and other cryogenic products. The equipment can cover operating temperatures from -1640C to 2000C.
Arms can be supplied as manual, hydraulic, electro-hydraulic with either hardwired or wireless remote control. Manually operated arms can be supplied with attachment brackets for the later addition of hydraulic operations. Operational limiting controls and other warning devices are available as optional extras. Woodfield Arms, although normally fixed in one jetty position, can be mounted on movable trailers or rail tracks to provide dockside flexibility.
Several types of quick connect/disconnect couplings are available for the full range of Loading Arms. An emergency disconnect coupling is also available as an operator initiated device or as part of a sequence controlled %u201Cshut down%u201D disconnect-system.
|
|
MLA 262
The MLA262 series consists of a frame type construction including separate supporting structure with floating product and/or vapour pipe. Full balance of the loading arm is provided by means of a %u201CCable wheel link%u201D rotating counterweight-balancing system.
The MLA262 series is specifically used for cryogenic or highly corrosive or toxic chemical service.
|
|
With the latest successful installation and commissioning of our LNG loading arms, we are pleased to add this new technology to our extensive portfolio.
Standard Design Features
Designed for minimum maintenance
Structurally supported product pipe
Stainless Steel product pipe
Rigid pantograph link (no wire ropes - low maintenance)
All bushes self lubricating
Hydraulic lines and fittings in stainless steel
All product swivels seals fully serviceable in situ
Loading arm fully balanced in all positions whilst empty
Optional Design Features
|
|
Marine Loading Arms
Woodfield Systems can offer the full range of both ambient and cryogenic marine loading arms.
|
|
The loading arm is fully balanced in all positions with two independent counterweight systems. It is a self-support structure%uFF0Cthe pipeline and the swivel joint endure not only the pressure from the media but also the gravity and the overturn moment of all load.
It is usually used on the river wharf and the small tanker.
|
|
The "BARCA" marine loader is the most simplified loading arm in our production programme.
It is very light in manipulation and very easy to install.
|
|
The "MINERVA" is our most common model, the pipe construction is self supporting.
If necessary, this loading arm can also be hydraulically operated and equipped with a vapour return line.
|
|
RC%uFF08Rotation Counterweight%uFF09manual marine loading arm
this is a typical rotary counterweight marine loading arm, all the vertical load and overturn moment should be supported by the base riser and supporting device, to make the pipeline and the swivel joints be free in theory, the balance system consists of a pantograph for transmitting balancing loads from the outboard arm to the secondary counterweight. It is manoeuvred only by one operator .It is easy operating and lower cost for various liquid loading/unloading
|
|
Our heavy duty model "ATLANTA" has a separate supporting structure and is mostly hydraulically operated.
This type of loading arm is very often equipped with an "Emergency Release System", with an automatic product cut off in case of danger.
Alarms can be installed to prevent that the loading arm is working outside his operating envelope.
|
|
|
Cryogenic loading arm is a new kind of marine loading arm which is used for conveying some cryogenic media such as LNG, ethylene. To select different materials for the main pipeline according to different temperature of products. The supporting structure of the arm is designed specially to prevent it from contacting the cryogenic pipeline, and to avoid the material performance changing in the condition of cryogenic temperature, such as cold shortness. the swivel joint-the key part of the loading arm is also designed specially to make the whole six pieces of swivel joint can be cycled by Nitrogen gas, in this case, it can put the vapor out of the swivel joint to avoid icing in the race way of swivel joint and protect the race way from being broken.
|
|
|
This type loading arm consists of two parts: the marine loading arm connected with vessel and the land loading arm connected with the local pipeline. It can make the loading arm work movably, to ensure all loading facilities can leave the site timely after loading or unloading, and hence to save enough space to do other work; all the power to operate the loading arm is supplied by the veghicle motot, the operaor only need to start-up the motor of the vehicle, then the loading arm can be operated with a remote controller, so it can be connected or disconnected with vessel or site pipeline easily.
|
|
|
|
|
|
|
Marine Loading/Unloading Arms are designed to the O.C.I.M.F. design and construction for marine loading arms and offers advantages in enhanced safety and reliability in operation. Marine Loading Arms need a minimum of service attention and only require routine maintenance.
Swivel Joints
The swivel joints are designed for minimum maintenance and incorporate unique design features whereby all seals can be replaced in situ. All swivels are of the proven wire raceway design, being single row ball track type with replaceable "clip in" wire raceways and are designed to withstand the effect of combined radial and axial loads and bending moments (without leakage) or ball track indentation. The split flange design allows the capability of changing the swivel (where required), without having to dismantle major boom elements.
Testing & Standards
Both ambient and cryogenic swivel technologies are well proven within the industry and the swivels have surpassed expectations in OCIMF and life cycle testing. (Third party certification available upon request)
With the excellent track record for safe and trouble free operation, the arms meet all the HSE safety and environmental requirements within the industry.
|
|
|
|
