The solution for when you want to be seen
The CSB 200 is a low cost AIS Class B Transponder designed specifically for the small commercial boat, fishing boat and leisure markets enabling the vessel not only to receive AIS broadcasts for surrounding vessels but also to transmit AIS information and therefore be "seen" by surrounding traffic.
Fully compliant with Class B Standards.
IEC62287-1 Class B, ITU-RM.1371-1, IEC61162-100, EN-60945.
Fit to vessels not required to fit Class A units.
Lightweight, rugged and easy to install.
Connect to an external VHF and GPS antenna.
Transmits own vessels position and AIS data (see below) and receives AIS information from other vessels, shore stations and navigational aids within VHF range.
|
|
TRANSAS AIS CLASS B MAKES PEACE OF MIND AFFORDABLE
Fitting an AIS Transponder helps you to see and be seen in all weather conditions, automatically identifying vessels in your area, helping you and your crew to stay safe.
Instantly switch between ‘receive’ only and ‘transmit and receive only’ modes for communication on your terms
Enables direct communication with other AIS targets, helping to avoid situations that can cause net damage
Available with the Transas world renowned Navigator software FREE and worth €300!
The compact AIS Class B unit is suitable for a variety of applications within the AIS environment. Certified, well-proven technology ensures users of the reliability and quality which has become the hallmark of Transas in today’s fast moving marine industry.
|
|
Active Diplexer AIS TX-RX - for ais transponder, to get two radio on the same antenna. Without power supplie,direct connection with VHF; included in the box: 2 coaxial cable 1 mt; 2 assembled PL connectors.
Box material: Metal. Fuse: Automatic Inside
|
|
|
The SI-60B is black box type receiver capable of displaying both class A and class B AIS information on NAVIS series chart plotters, other manufacturer's chart plotters or PC based navigation software - in real time. The unit features both RS-232 and RS-422 I/O ports and user selectable baud rate for ease of installation.
|
|
The SeaTraceR AIS B Transponder from SevenStar was one of the first to be designed following the release of the IEC- 62287-1 specification. It utilises the most sophisticated digital signal processing and software algorithms to implement the required CS-TDMA transmitter and receiver functions. Robust and resilient to the stresses of life at sea, the SeaTraceR is housed in an IP-65 rated aluminium enclosure with matching and versatile mounting hardware, all of which is protected with a sea-water resistant coating under a heavy-duty powder-coat external finish.
Combined with a chart plotter or AIS-enabled radar set, it takes their performance into the next generation - once you've seen it in action, you won't believe you could have sailed without it!
|
|
Designed to meet or exceed current specifications from IMO, IEC and IALA.
TR-2600 with its dedicated Base Station Controller (BSC) can operate as a stand-alone unit, or together with a standby unit in a hot standby configuration.
If configured, the standby unit will automatically continue operation if the main unit fails, or is disabled for maintenance purposes.
TR-2600 can easily be interfaced to customised coastal surveillance systems, combining radar and AIS surveillance. All configurations can be done via the 10Base-T Ethernet interface or via a RS-422/232 serial line.
All data received and transmitted as output to a configurable unicast IP address and/or as a broadcast message, in this way the data can be used locally on a LAN or filtered to be available on a wider network.
|
|
|
|
|
|
|
AWAIS-800 ClassB AIS TRANSPONDER
AIS (Automatic Identification System) was designed to fulfill a need for vessels to know the position, details and navigation intentions of other vessels within VHF range for improved safety and collision avoidance.
Data interface: RS-422,RS-232
Data format:NMEA-0183,IEC61162-2
Power supply:DC 12V ～ 32V
Output Power ：≥ 2W
With 12 channels GPS
The body of AWAIS-800 is very light and convenient.
Waterproof.IP65
FEATURES
Compliant with following standards as applicable: ITU-RM.1371-3, IEC60945，IEC61162-2，IEC62287-1
SPECIFICATION
AWAIS-800 CLASS B AIS TRANSPONDER
1 TDMA Transmitter, 2 TDMA Receivers
Frequency Range: 156.025 MHz ～ 162.025MHz
Default Channels: CH87B(161.975MHz), CH88B(162.025MHz)
Bandwidth: 25KHz
Output Power: ≥ 2W
Modulation Method: GMSK
Data Interfaces: RS-232 / RS-422(IEC61162-2)
Baud Rate: 9600bps～38400 bps
Data format: NMEA-0183,IEC61162-2
Power Supply: DC 12V ～ 32V
Dimension: 222(H)×145(W)×58(D)mm
Weight: 1.8 kg
|
|
| ... products without information |
| |
The CSB 200 is a low cost AIS Class B Transponder designed specifically for the small commercial boat, fishing boat and leisure markets enabling the vessel not only to receive AIS broadcasts for surrounding vessels but also to transmit AIS information and therefore be ”seen” by surrounding traffic.
*
Fully compliant with Class B Standards.
o IEC62287-1 Class B, ITU-RM.1371-1, IEC61162-100, EN-60945.
o Fit to vessels not required to fit Class A units.
*
Lightweight, rugged and easy to install.
o Connect to an external VHF and GPS antenna.
*
Transmits own vessels position and AIS data (see below) and receives AIS information from other vessels, shore stations and navigational aids within VHF range.
*
Connect to:
o On board PC running a compatible Navigation Program, or
o Compatible Marine Chart Plotters.
*
Gives the skipper a visual interpretation of the name, position, course and speed of other vessels within VHF range.
*
NB Ask us for information on the AST 100 Antenna Splitter
|
|
|
|
